High Channel Count Vibration Test Control: The Spider-80X vibration test controllers have voltage and IEPE inputs which are ideal for shock, vibration and acoustic measurement or general purpose voltage measurement. Each Spider-80X vibration controller is equipped with input channels which accurately measure and record both dynamic and static signals. The mass flash memory records 8 channels of streaming signals while simultaneously computing real-time and frequency based functions. An embedded signal source channel provides various signal output wave forms that are synchronized with the input sampling rate. High Dynamic Range: The Spider-80X performance is the best in class with the highest dynamic range of any similar product. With patented technology, the Spider-80X achieves 150 dBFS input dynamic range (defined in the time domain). Each measurement channel detects signals as small as 6 A A A A A A A A V and as large as A A A A A A A A 20 V. Such high dynamic range eliminates the need for input range and or gain settings of traditional data acquisition systems. A high-speed floating point DSP manages the data input/output and real-time processing. The Spider-80X is also configured with RAM and onboard flash memory for mass data storage. Special thermal and low power designs eliminate the need for a cooling fan. Vibration Test Control A A A AcA A A A A A A A Operation Mode: The Spider-80X vibration test controllers are controlled by a host computer or run in Black Box mode, where a preprogrammed schedule is downloaded to the unit and started manually or based on an event trigger. The ability to use any vibration test controller in Black Box mode or in a network distributed system means that users are able to place modules close to the measurement object. Full Vibration Test Control Software Suite: The Spider-80X system has a full vibration test control software suite available. EDM (Engineering Data Management) software by Crystal Instruments features a modern intuitive interface for vibration test control needs. The Spider-80X is also compatible with the iPad App version of EDM. Contact Crystal Instruments for more details. Specifications: 1. Inputs: 8 BNC connectors per unit, units are networked to form up to 1024 inputs, voltage or IEPE, single-ended or differential, AC or DC couptdng, 150 dBFS dynamic range, 24-bit A/D converters, range A A A A A A A A 20 volts, up to 102.4 kHz fs per channel 2. Outputs: 2 BNC connectors per unit, 100 dB dynamic range, 24-bit A/D converters. A A A A A A A A 10 volts 3. Channel Phase Match: Better than A A A A A A A A 1.0 degree up to 20 kHz among all channels 4. Power: Powered from external DC power 5. Computer Connections: 100Base-T, RJ45 female connector supports connection to PC or network switch 6. Internal Memory: Flash memory for data storage is 4 GB per unit 7. Real Time Analysis Functions: Data recording, Math (+,-,*,/), integration, differentiation, FFT, average, window, auto power spectrum, cross-spectrum, FRF, coherence, real-time filter 8. Operation Modes: Connected to a computer or stand alone Black Box mode.a
