At688 Insulation Resistance Meter - Color: Gray + White

At688 Insulation Resistance Meter - Color: Gray + White

Price: 540.0 USD / Unit

Get Latest Price

Minimum Order Quantity :

1 Unit

In Stock

In Stock

Product Specifications

Resistant FeatureAnti-interference, Overvoltage Protection
Usage & ApplicationsInsulation Performance Test for Electronic Components, Wires, Cables, Dielectric Materials, Electrical Equipment
Power RatingMax 30 VA
Product TypeDigital Insulation Resistance Tester
Frequency (MHz)50/60 Hertz (HZ)
Protection SystemOvervoltage Protection, Overcurrent Protection
Size264(W) * 107(H) * 350(D) mm
Warranty12 months
ColorGray + White
Operating Temperature10~40 Celsius (oC)
Cable TypeATL507 Insulation Test Cable, ATL108 RS232 Communication Cable
Weight5 Kilograms (kg)
PhaseSingle Phase
Display Type3.5-inch LCD Display
MaterialCold-Rolled Steel Metal Chassis
Frequency50/60 Hertz (HZ)
ConductorATL507 Test Clip (4-terminal Insulation Test Probe)
Features1V~1000VDC Adjustable Output, 100k ~10T Range, Simultaneous Leakage Current Display, RS232/Handler/USB Interface
FOB PortShanghai
Payment TermsPaypal, Delivery Point (DP), Telegraphic Transfer (T/T), Western Union, Others, Letter of Credit (L/C)
Supply Ability10000 Per Year
Delivery Time5 Days
Sample PolicySample costs shipping and taxes has to be paid by the buyer
Main Export Market(s)Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe
Main Domestic MarketAll India

Product Overview

Key Features


AT688 INSULATION RESISTANCE METER

Power Supply198VAC-242VAC 50/60 Hz Power: maximum 30 VA

Measuring range: 100 k~10 T
Output voltage (1.0 VDC ~ 1000 VDC )3.5 inch LCD display with automatic equipment interface Leakage current & insulation resistance Display

--Output voltage (1.0 VDC ~ 1000 VDC )
--3.5 inch LCD display
--With automatic equipment interface
--Leakage current & insulation resistance Display

AT688 is an insulation resistance tester controlled by a high-performance ARM processor. The unique insulation resistance and leakage current are tested and displayed simultaneously, with six range testing,allowing the insulation resistance measurement range to reach 100k~10T, with a maximum display number of 9999 digits. The testing speed can reach 55 times/second, and ultra high speed testing provides the best solution for automated production.

The instrument has sorting function and sorting sound settings. It can also be equipped with a Handler interface for automatic sorting systems to complete fully automatic pipeline testing and equipped with RS232C interface for remote control,data acquisition and analysis.

AT688 can measure the insulation resistance of various electronic components, equipment, dielectric materials, wires and cables, etc.
