Anti-lightning Submersible Liquid Level Transmitter

Based on BCM silicon piezoresistive technology, model LV36 submersible liquid level transmitters are designed for gauge pressure measurements. This product is made from 316L stainless steel with rigid and robust construction, and has a cable with vent hose which is designed for submersible applications.

Lv36 level transmitters are made of a Wheatstone bridge circuit. Various output signals, including millivolts signal (80 mV@1 mA) and amplified signals (4~20 mA, 0~5V or 0~10 V), are available. The measuring accuracy is up to 0.25 %fso. These transmitters possess low temperature coefficients of 0.02 %fso/oC for both Zero and Span within the compensated temperature range (0~50 oC).

1. Integrated construction, rigid and robust
2. Measuring ranges: 0~0.2, ..., 0~200 mH2o
3. Various output signals: transducers: full scale output 80 mV@1 mA transmitters: 4~20 mA, 0~5 V, 0~10 V
4. Measuring accuracy: 0.25 %fso (standard), 0.5 %fso
5. Materials : 316L SS (pressure membrane); 316 SS (housing)
6. Housing environment protection: IP 68
