Automatic Air Plasma Cutting Machine With 1 Year Of Warranty

CUT -80 Inverter Based Air plasma cutting machine, three phase highly efficient Model, Cuts metal up to 16 mm thick (SS), 22-25 mm cut (MS) with the help of Air Compressor (sold separately) reliable and cheap and operate as compared to Oxy-Acetylene cutting) MODEL CUT -80 (Inverter Type IGBT) Input power voltage (frequency): 3 Phase 380-415V A A 10%, 50/60 HZ Rated input power capacity: 14-15Kva No-load voltage: 270V Output current adjustment range: 20-100 Rated output voltage: 120V Rated duty cycle: 60% No-load consumption: 100 W Arc-starting: Non - Contact Efficiency: 80% Power factor (COSA A ): 0.93 Weight (Approx.): 40 KG. Measurement (Approx.): 558*A 609*A 330mm Insulation class: H Gas Supply: Compressed Air Protection class: IP21 S, EN, IS 1581, IEC, CE Air Pressure: 6kg mm2 (200 Ltrs/Min) Maximum cutting thickness: 14 mm Accessories: 1. Hand Torch 2. Earth Clamp 3. Air Filter
