Ai Security Ptz Thermal Camera - Aluminum Alloy, 10km Viewing Distance, 1920x1080 Pixels | Intelligent Alarm, Starlight Sensitivity, Multiple Detection Functions

China TianYing TY-P9 AI security IP PTZ 10km HD 800mm CCTV 150mm thermal camera is the best low-cost day / night intelligent behavior analysis and long range fire detection observation system.

The PTZ camera is including 2MP 13~800mm wide spectral no chromatic aberration 0.0001Lux starlight CCTV camera, VOx 40mk 150mm fixed focus thermal camera, multiple protections 0.06A repeatability accuracy pan/tilt, intelligent analysis module, integrated protective housing and option 30km 2Hz eye safe laser rangefinder. The system features multiple image enhancement, intelligent detection alarm, stable reliable operation and reasonable cost.

Mounted on a stabilized base, this intelligent PTZ CCTV thermal camera system provides no blind spot undetected with a 24/7 situational awareness, that can realize high precision VCA detection, fire detection and real-time alarms, mainly used for forests, border and coastal defense, grasslands, ports, military fortresses etc.

AI security surveillance PTZ 10km 2MP 13~800mm CCTV 150mm thermal camera specifications:
Model TY-P9
Day Night TV Camera
Sensor 1/1.8 inch COMS 2 Megapixel 1920 x 1080 50Hz/60Hz.
Signal to noise ratio a Y57dB (AGC OFF)
Electronic Shutter Speed 1i 1/30,000s
Coding format H.265(MP)/H.264i HP/MP/BPi /MJPEG
Video bit rate 32Kbps~16Mbps
Storage Capabilities TF card, up to 256G
Network Protocol ONVIF, GB/T 28181, CGI, HTTP, RTSP, RTP, TCP, UDP etc
Min. Illumination Color: 0.0002Lux; B/W: 0.0001Lux;
Image enhancement 3x optics defog, WDR, ELS, HLC, BLC, 3D NR etc
Image adjustment White Balance, corridor mode, flip etc
Wavelength range 400nm ~ 1100nm (0.4~0.7I m daylight, 0.7I m~1.1I m NIR)
Field of View (3.75um-LAN),A Approx 33A x 18.5A ~ 0.51A x 0.29A
Focal Length 12.5~800mm continuous optical zoom.
Aperture F11.7
Close-up distance, m Approx 12m
Lens control electric zoom, electric/auto focus, electric/auto optical filter
Viewing distance a Y10km (can be 15km) for human
Thermal Camera
Sensor Uncooled vox sensor
Resolution 384 x 288, option 640x512
Pixel Size 12I m
Spectral range 8I m~14I m
NETD a 25A C,F#1.0
Focal Length 150mm
Frame Rate 25Hz
Digital Magnification 2x, 4x
Fire detection distance a Y11km for 2mA 2m fire source target
Option Eye Safe Laser Rangefinder
Wavelength 1.5Aum
Beam divergence approx 0.8mrad
Ranging capability 30km(can be 40km) for for building/house in 23.5km visibility
Measuring rate 2Hz
Accuracy a 10m (+/-1m only LRF)
Laser classification Class 1M/3R, option class 1(ICE 60825-1:2007 and ANSI 136.1-2007)
AI Intelligent analysis
Fire point detection support
Fire area shielding support
Thermal imaging detection alarm Support area intrusion, montion detection, boundary detection, out of the area detection and alarm functions
Pyrotechnic identification Support, the minimum identification of 1A 1 pixel fire point
Abnormal temperature alarm Support
Personnel detection Support
Vehicle detection Support
Video analysis Motion detection, occlusion alarm, cordon, area intrusion, area departure, personnel gathering, etc., support humanoid and vehicle-shaped recognition to effectively reduce environmental interference false alarms
Pan/Tilt
Carrying capacity 30kg(top load)
Repeatability accuracy 0.06A
Direction range azimuth:360A continuous; elevation:+60A ~-80A
Directing speed range for azimuth 0.01A /s to 30A /s
Directing speed range for elevation 0.01A /s to 15A /s
Presets 256 presets
Function Cruise, proportional zoom, power-off memory, 3D positioning, watch, scheduled task
Communication protocol Pelco-D
Material Precise casting aluminum alloy
Input / Output
Power supply DC24V ~ 48V
Network interface 1A 10Base-T/100Base-TX,RJ45
Control interface RS485
Audio interface 1 x audio input, 1 x audio output
Alarm interface 2 x alarm input, 1 x alarm output
Environmental Adaptability
Operating Temperature -40A C to +70A C
Working humidity 10% to 95%
Windproof Strong wind resistance
Protection grade IP66, TVS6000V lightning protection, ant
