1 Ghz Spectrum Analyser - Crt 6 Inch Display, 285x125x380 Mm, 7 Kg | Frequency Range: 150khz To 1050mhz, Built-in Tracking Generator, 4 Digit Display
Price: 10 INR / Piece
Get Latest Price
Minimum Order Quantity :
1 Piece
Brand Name :
Teknik
In Stock
Product Specifications
| Usage | Electronic Testing and Measuring Equipments |
| Power Source | AC Mains, 100-240V, 50/60 Hz |
| Voltage | 100-240V |
| Product Type | 1 Ghz Spectrum Analyser |
| Capacity | 1 GHz |
| Model No | SA-1G |
| Core Components | RF Front End, Display Module, Processing Unit |
| Automation Grade | Manual |
| Feature | High Frequency Range, Multi-mode Analysis, Low Noise |
| Temperature Range | 0AdegC to 50AdegC |
| Application | Electronic Testing and Measuring Equipments |
| Measurement Range | 9 kHz to 1 GHz |
| Frequency | 9 kHz - 1 GHz |
| Accuracy | A+-1 dB |
| Equipment Materials | High Grade Industrial Plastic & Metal |
| Type | Spectrum Analyser |
| Display Type | Digital LED Display |
| Dimension (L*W*H) | 420 mm x 178 mm x 170 mm |
| Weight | Approx. 5.5 kg |
| Sample Available | Yes |
| Sample Policy | Sample costs shipping and taxes has to be paid by the buyer |
| Packaging Details | carton box, export quality also available |
| Main Domestic Market | All India |
| Certifications | ISO 9001, 14001 ,CE |
Product Overview
Key Features
Micro Teknik is manufacture, exporters & suplliers
General Display : CRT 6 Inch. 8 x 10 internal graticule.Trace rotation : Adjustable on front panel.Line Voltage : 220V 10%, 50-60 Hz.Power consumption : Approx. 25wOperating temp. +10C to +40C Protective System : Safety class 1 (IEC 1010-1).Cabinet : 285 (W) x 125 (H) x 380 (D) mm.Weight : Approx 7 Kg.Accessories Supplied : Instruction Manual, power cord.Optional Accessories : Sniffer Probe: (1. High impedance Probe2. Magnetic field Probe3. Electric Field Probe)
Features1. Frequency Range : 150KHz to 1050MHz2. 4 Digit Display : Center & Market frequency,0.1 MHz resolution3. Amplitude range - 100dBm to + 13dBm4. Filters : 20KHz, 250KHz & Video Filter.5. Built-in Tracking generator : 0.15 MHz to 1050 MHz 6. Output Power : + 1dBm to -50dBm (50 ohms)
