Technical Data:-
Bag width standard: 12 mm or 18 mm
Special bag width: As per requirement
Bag length: min. 25 mm max. 45 mm
Special bag length: up to 45 mm
Filling volume per bag: approx. 0,2 up to 1,0 g, adjustable
Output bags/min: approx. (2×350)=700/min
Number of lanes: Independent
Speed : 300-350 ppm
Width of film reel: 31 mm or 41 mm + special width
Diameter of film reel core: 70/76 mm
sealing pressure: up to 1000 N
Air connection: 6 bar
Wattage: approx. 5 KW
Voltage supply standard: 400V/3/N/PE/50Hz
Protection class: IP 54
Color standard: stainless steel , Silver, Red
Packaging material: Non woven Filter Paper,
Technical details :
PLC Mitsubishi Japan
HMI Mitsubishi Japan
Geared Motor : Lenze, Bonvario (Italian)
A.C. Drive : Mitsubishi (Japanese)
Pneumatic : Festo (German) , SMC (Japanese), Pneumax (Italian)
Sensor : P&F (German)
Temperature controller : Omron, PID (Japanese)
Contact parts : Stainless steel 304 Food Grade
Auto Counting system
Conveyor system
All Electrical Parts : Schneider (France)
Suhan Pack Teach Pvt Ltd has professional management and global after sales service teams with its corporate offices centrally located in West Delhi. The focus of the company is on incorporating the latest Software technologies with strong global support and service for our packaging machines like High Speed Snus Packing Machine, Snuff Packing Machine, Swedish Snus Packing Machine, Tobacco Packing Machine popularly known as Filter Khaini Packing Machine and Naswar Packing Machine as per the requirements and specifications of each individual client through a wide range of industries and products. AUTOMATIC FILLING MACHINE DEVELOPMENT CENTER : Suhan Pack Tech Pvt Ltd has a state-of-the-art Development center focused on the design and development of its packaging machines. The complete research, development and testing of the company automatic filling machine, Food, Filter Khaini Packing Machine, Tea packaging machine and Snus packaging machine lines are done under one roof at the R&D center. Suhan Pack Tech Pvt Ltd development center uses the latest Solid Edge 3D Modeling Software for design and analysis whereas E-plan software is being used for electrical and controls to design and manufacture the highest quality range of packaging machines.
