Ue 100 Series Pressure, Vacuum, Differential Pressure And Temperature Switches Max. Voltage: 15a 125/250/480 Vac Volt (V)

We are Trading Ue 100 Series Pressure, Vacuum, Differential Pressure And Temperature Switches in Xian, Shaanxi, China. Specifications as given below:-

Specifications
Storage temperature -65 to 160A F (-54 to 71A C)
Ambient TEMPERATURE -40 to 160A F (-40 to 71A C); models 520-525, 540-548, 700-706, 15731-15736: 0 to
limits 160A F (-18 to 71A C); Set point typically shifts less than 1% of range for a 50A F (28A C)
ambient temperature change
Set point repeatability Temperature models: A 1% of adjustable range
Pressure models 15623, 15731-15737, 171-174, 218, 270-376, 520-535, 540-543, 700-
706, 560-564: A 1% of adjustable range; models 190-194, 183-189, 483-494, 544-548,
565-567, 610-680, 15884: A 1.5% of adjustable range
Internal set point lock on all pressure models
Shock Set point repeats after 15 G, 10 millisecond duration
Vibration Set point repeats after 2.5 G, 5-500 Hz
Enclosure Die cast aluminum, epoxy powder coated, gasketed, captive cover screws
Enclosure classification Enclosure type 4X
Switch output One SPDT snap action switch; switch may be wired a normally opena or a normally closeda
Electrical rating 15A 125/250/480 VAC resistive except for H100-15623, 15731-15737, 15884, 20A
125/250/480 VAC resistive, B100-13546 and E100-13545, 22A/480 VAC. Electrical
switches have limited DC capabilities at 24-30 VDC, 2A resistive and 1A inductive. 125
VDC, 0.5A resistive, 0.03A inductive.
