Tesi Laser Cutting Machines

We are highly celebrated distributor and supplier of TESI Laser Cutting Machines in New Delhi, Delhi, India. TESI J is the ideal solution when a compact yet powerfull machine is needed, despite its small footprint quality and performance are at highest level. The compact laser cutting centre features an easily accessible working area dimensions are 1200mm X1000mm, laser souresa

Description TESI a J

TESI a J is the most compact , economic and flexible laser cutting and marking system, ideal for who produces small pieces, requiring at the same time the quality and the performance of the most powerful ones.
This unit can be equipped with different laser sources , featuring output power up to 200 watt axis speed up to 140mt/min, acceleration up to 1.5 G and machinable area of 1000X1200mm.

Protection and aspiration Cabinet.

The working area completely isolated from the external environment by mean of an openable cover.

Technical Details:
Control unit Digital NC + Computer
Laser source power Up to 200 W
Max XY simultaneous Speed 140 mt/min
Rapid Z speed 1.5mt/sec2
X Axis Stroke 1200mm
Y axis Stroke 1000mm
Z axix stroke 50 mm
Height from ground 900mm
General Weight 1200kg
Dimensions 2000X2200mm
Positioning precision +/- 0.1mm
XY axis positioning system Belt
Z axis rack
Power supply 400V/50 Hz/12KVA
Pneumatical power supply 250l/min
