Study Of P/i & Convertor Application: Lab Experiment

I/P Convertor : Input : 4-20 mA DC output : 3-15 PSIG
Pressure Gauge: Bourdon type 0-2 kg/cm2
P/I Convertor : Input : 0-1 bar Output:4-20 mA DC
Digital Current Source/ Meter: Digital indication of current input and output
Range 0-20 mA DC
Pressure Regulator: 0-2 kg/cm2
piping: Size
An ENGLISH instruction manual consisting of experimental procedures, block diagram etc. will be provided along with the apparatus.
The whole set-up is well designed and arranged on a rigid structure painted with industrial PU paint.
An ENGLISH instruction manual consisting of experimental procedures, block diagram etc. will be provided along with the apparatus.
The whole set-up is well designed and arranged on a rigid structure painted with industrial PU paint.


SERVICES REQUIRED

Electricity Supply: Single Phase , 220 V AC, 50 Hz, 5 Amp.
Table for setup support.
compressed air supply @ 2 CFM at 2 kg/cm2 pressure.
