Standard Unit Coolers-m Series Inside Diameter: 25 Millimeter (Mm)

Backed by a team of highly skilled professionals, we are the eminent Exporter, Manufacturer & Supplier of Standard Unit Coolers-M Series in Konya, Konya, Turkey.
"M SERIES / MSA - MSS - MSO Model

Standart Unit Air Coolers

Evaporator Coil

Fin Geometries : 40 mm x 35 mm
Copper tubes A 1/2""
V type aluminium fins.
The finned coils are designed with aluminium fins spaced at 6 - 8 - 10 mm, crimped onto copper tubes.
Header inlet and outlet tube connections made of copper.
Maximum operating pressure 21 bar.
Staggered copper tubes.
The coil circuit are designed for refrigerants R404A, R507C, R22, R134A, R407C.
Refrigerant distribA tA r.

Casing

Electrostatic powder coated RAL 9016 galvanized steel.
Stainless steel casing as optional.
Side panels are removable.
Hinged / Folding drain tray is standard for all models.
Intermediate drain tray.

Fans

Selection of a unit cooler with various fan number / diameter combinations offering the dimensional and air throw characteristics best adapted to the size of the cold room.
Selections should be confirmed by your BuzA elik Technical Specialist.
Standard or low noise level are available.
Different kinds of motors available as optional. (EC or AC)
Motor protection IP54 insulation class F.
Different kinds of accessories available as optional. (Axicool Fans, FlowGrid etc.)
Working conditions - 40A C/ + 50A C.

Defrost
B1 type defrost system suitable for 0A C/ + 5A C cold room applications. Defrost heaters are applied on heat exchanger coil.
