Smart Pv Solar Combiner Box - Ip65 Cold Rolled Steel, 12 String Input, 1000v Max Voltage | Dc Fused Protection, Lightning Protection, Waterproof Terminals
Share
Smart Pv Solar Combiner Box - Ip65 Cold Rolled Steel, 12 String Input, 1000v Max Voltage | Dc Fused Protection, Lightning Protection, Waterproof TerminalsSmart Pv Solar Combiner Box - Ip65 Cold Rolled Steel, 12 String Input, 1000v Max Voltage | Dc Fused Protection, Lightning Protection, Waterproof TerminalsSmart Pv Solar Combiner Box - Ip65 Cold Rolled Steel, 12 String Input, 1000v Max Voltage | Dc Fused Protection, Lightning Protection, Waterproof TerminalsSmart Pv Solar Combiner Box - Ip65 Cold Rolled Steel, 12 String Input, 1000v Max Voltage | Dc Fused Protection, Lightning Protection, Waterproof TerminalsSmart Pv Solar Combiner Box - Ip65 Cold Rolled Steel, 12 String Input, 1000v Max Voltage | Dc Fused Protection, Lightning Protection, Waterproof TerminalsSmart Pv Solar Combiner Box - Ip65 Cold Rolled Steel, 12 String Input, 1000v Max Voltage | Dc Fused Protection, Lightning Protection, Waterproof TerminalsSmart Pv Solar Combiner Box - Ip65 Cold Rolled Steel, 12 String Input, 1000v Max Voltage | Dc Fused Protection, Lightning Protection, Waterproof TerminalsSmart Pv Solar Combiner Box - Ip65 Cold Rolled Steel, 12 String Input, 1000v Max Voltage | Dc Fused Protection, Lightning Protection, Waterproof TerminalsSmart Pv Solar Combiner Box - Ip65 Cold Rolled Steel, 12 String Input, 1000v Max Voltage | Dc Fused Protection, Lightning Protection, Waterproof TerminalsSmart Pv Solar Combiner Box - Ip65 Cold Rolled Steel, 12 String Input, 1000v Max Voltage | Dc Fused Protection, Lightning Protection, Waterproof TerminalsSmart Pv Solar Combiner Box - Ip65 Cold Rolled Steel, 12 String Input, 1000v Max Voltage | Dc Fused Protection, Lightning Protection, Waterproof TerminalsSmart Pv Solar Combiner Box - Ip65 Cold Rolled Steel, 12 String Input, 1000v Max Voltage | Dc Fused Protection, Lightning Protection, Waterproof TerminalsSmart Pv Solar Combiner Box - Ip65 Cold Rolled Steel, 12 String Input, 1000v Max Voltage | Dc Fused Protection, Lightning Protection, Waterproof TerminalsSmart Pv Solar Combiner Box - Ip65 Cold Rolled Steel, 12 String Input, 1000v Max Voltage | Dc Fused Protection, Lightning Protection, Waterproof TerminalsSmart Pv Solar Combiner Box - Ip65 Cold Rolled Steel, 12 String Input, 1000v Max Voltage | Dc Fused Protection, Lightning Protection, Waterproof TerminalsSmart Pv Solar Combiner Box - Ip65 Cold Rolled Steel, 12 String Input, 1000v Max Voltage | Dc Fused Protection, Lightning Protection, Waterproof TerminalsSmart Pv Solar Combiner Box - Ip65 Cold Rolled Steel, 12 String Input, 1000v Max Voltage | Dc Fused Protection, Lightning Protection, Waterproof TerminalsSmart Pv Solar Combiner Box - Ip65 Cold Rolled Steel, 12 String Input, 1000v Max Voltage | Dc Fused Protection, Lightning Protection, Waterproof TerminalsSmart Pv Solar Combiner Box - Ip65 Cold Rolled Steel, 12 String Input, 1000v Max Voltage | Dc Fused Protection, Lightning Protection, Waterproof TerminalsSmart Pv Solar Combiner Box - Ip65 Cold Rolled Steel, 12 String Input, 1000v Max Voltage | Dc Fused Protection, Lightning Protection, Waterproof TerminalsSmart Pv Solar Combiner Box - Ip65 Cold Rolled Steel, 12 String Input, 1000v Max Voltage | Dc Fused Protection, Lightning Protection, Waterproof TerminalsSmart Pv Solar Combiner Box - Ip65 Cold Rolled Steel, 12 String Input, 1000v Max Voltage | Dc Fused Protection, Lightning Protection, Waterproof TerminalsSmart Pv Solar Combiner Box - Ip65 Cold Rolled Steel, 12 String Input, 1000v Max Voltage | Dc Fused Protection, Lightning Protection, Waterproof TerminalsSmart Pv Solar Combiner Box - Ip65 Cold Rolled Steel, 12 String Input, 1000v Max Voltage | Dc Fused Protection, Lightning Protection, Waterproof TerminalsSmart Pv Solar Combiner Box - Ip65 Cold Rolled Steel, 12 String Input, 1000v Max Voltage | Dc Fused Protection, Lightning Protection, Waterproof TerminalsSmart Pv Solar Combiner Box - Ip65 Cold Rolled Steel, 12 String Input, 1000v Max Voltage | Dc Fused Protection, Lightning Protection, Waterproof TerminalsSmart Pv Solar Combiner Box - Ip65 Cold Rolled Steel, 12 String Input, 1000v Max Voltage | Dc Fused Protection, Lightning Protection, Waterproof TerminalsSmart Pv Solar Combiner Box - Ip65 Cold Rolled Steel, 12 String Input, 1000v Max Voltage | Dc Fused Protection, Lightning Protection, Waterproof TerminalsSmart Pv Solar Combiner Box - Ip65 Cold Rolled Steel, 12 String Input, 1000v Max Voltage | Dc Fused Protection, Lightning Protection, Waterproof TerminalsSmart Pv Solar Combiner Box - Ip65 Cold Rolled Steel, 12 String Input, 1000v Max Voltage | Dc Fused Protection, Lightning Protection, Waterproof TerminalsSmart Pv Solar Combiner Box - Ip65 Cold Rolled Steel, 12 String Input, 1000v Max Voltage | Dc Fused Protection, Lightning Protection, Waterproof TerminalsSmart Pv Solar Combiner Box - Ip65 Cold Rolled Steel, 12 String Input, 1000v Max Voltage | Dc Fused Protection, Lightning Protection, Waterproof TerminalsSmart Pv Solar Combiner Box - Ip65 Cold Rolled Steel, 12 String Input, 1000v Max Voltage | Dc Fused Protection, Lightning Protection, Waterproof TerminalsSmart Pv Solar Combiner Box - Ip65 Cold Rolled Steel, 12 String Input, 1000v Max Voltage | Dc Fused Protection, Lightning Protection, Waterproof TerminalsSmart Pv Solar Combiner Box - Ip65 Cold Rolled Steel, 12 String Input, 1000v Max Voltage | Dc Fused Protection, Lightning Protection, Waterproof TerminalsSmart Pv Solar Combiner Box - Ip65 Cold Rolled Steel, 12 String Input, 1000v Max Voltage | Dc Fused Protection, Lightning Protection, Waterproof TerminalsSmart Pv Solar Combiner Box - Ip65 Cold Rolled Steel, 12 String Input, 1000v Max Voltage | Dc Fused Protection, Lightning Protection, Waterproof TerminalsSmart Pv Solar Combiner Box - Ip65 Cold Rolled Steel, 12 String Input, 1000v Max Voltage | Dc Fused Protection, Lightning Protection, Waterproof TerminalsSmart Pv Solar Combiner Box - Ip65 Cold Rolled Steel, 12 String Input, 1000v Max Voltage | Dc Fused Protection, Lightning Protection, Waterproof TerminalsSmart Pv Solar Combiner Box - Ip65 Cold Rolled Steel, 12 String Input, 1000v Max Voltage | Dc Fused Protection, Lightning Protection, Waterproof TerminalsSmart Pv Solar Combiner Box - Ip65 Cold Rolled Steel, 12 String Input, 1000v Max Voltage | Dc Fused Protection, Lightning Protection, Waterproof Terminals

Smart Pv Solar Combiner Box - Ip65 Cold Rolled Steel, 12 String Input, 1000v Max Voltage | Dc Fused Protection, Lightning Protection, Waterproof Terminals

Price: 96 USD / Piece

Get Latest Price

Minimum Order Quantity :

1 Piece

Brand Name :

Danick

In Stock

In Stock

Product Specifications

MaterialCold rolled steel
DimensionsNA
Max. PV string parallel inputs12 strings
Output strings1 string
Max. PV string voltage1000Vdc
Rated fuse current for each string10A/15A
Input cable waterproof connectorPG cable gland / MC4
Output cable waterproof connectorPG cable gland / MC4
Output DC Circuit BreakerNA
PV special lightning protection moduleDC1000V-3P/40KVA SPD
Protection DegreeIP65
Environment Temperature40 to +70 Celsius
Environment Humidity< 90% No condensation
Altitude<3000m
InstallationIndoor and Outdoor
Type of installationWall mount
FeaturesOutdoor use, High voltage, Easy install, Safe wiring, Reliable system, High quality, Versatile, Monitoring
Product TypeOther, PV Solar Combiner
PowerDC
Switch ModeManual, Other
SizeStandard

Product Overview

Key Features

A Photovoltaic (PV) combiner box is a device used in solar power systems to consolidate multiple strings of solar panels into a single output. It provides a safe and convenient way to manage the electrical wiring of multiple panels and reduce the number of connections required. The combiner box also includes over-current protection devices, such as fuses or circuit breakers, to protect the system from electrical faults.
