Sim-2 Advanced Audiometric Room With Double Walls, Triple Window And Forced Ventilation

We are engaged in manufacturing and exporting excellent quality SIM-2 Advanced Audiometric Room With Double Walls, Triple Window And Forced Ventilation to our valuable clients.
-Designed and fabricated in accordance with: ISO 9001:2008, ISO 717, 93/42/CEE IEC 601.1, ANSI S3.1, ISO 8253-1 and ISO 11957
-Two booths structure: one inside the another
-Two double panels at every side
-Two spaces : one for a patient and another for medician
-Compatible with different types of audiometers
-External Dimensiones 210x210x240 cm
-Double walls in each booth,90 mm of thickness each one
-Advanced soundproofing and multilayer structure (see the scheme at the left)
-Robust wooden structure to minimize any possible vibration
-External finishing: wood
-Soundproofing material inside the panels
-Two doublea glass windows with vacuum chamber.
-Soundproofing at 8 kHz: 73 dB approximately
-Soundproofed door
-3 locking point for Door
-Floor: Silent Blocks and antivibration material
-Interior Lighting
-Ventilation: Forced, by fan
-Audiometer connection: two plates
-Type of connection: Jack stereo, male 6,35 mm A
-Exterior table: with a foot, washable
-User Manual included the installation instructions
-Approximate weight: 1480 kg
-CE Mark ( Medical device Class I)
