Silicon Carbide Ceramic Foam Filter For Malleable Castings Diameter: 40-500 Millimeter (Mm)

one pallet Piece/Pieces

42 Piece/Pieces

filter for casting

in iron cassting ,water treatment ,air purification and other field

Round ,square ,custom geometric shapes

Round ,square

80-90%

Very well

40-500 Millimeter (mm)

many kinds Millimeter (mm)

40-500 Millimeter (mm)

Multiple Specifications Millimeter (mm)

40-500 Millimeter (mm)

Multiple Specifications Inch (in)

Three years

3years

All India

All India

TIANJIN SHANGHANG ,CHINA

TIANJIN ,SHANGHAI ,IN CHINA

Yes

Yes

Product Selection 1) Select suitable temperature filter according to kinds of alloy, the filter should not exceed temperature and damage. 2) Select suitable bore density, purification is fit in with quality of casting. 3) Select dimension of suitable filter, not increase time of moulding. 4) Reduce the second dreg. 5) Porosity: filter 80-90% when founding Attention please: 1) The product of other specifications can also be prepared according to customers' requirement. 2) PPI (Pores Per Inch), the ppi means the number of holes per inch. Specifications of ACE CFF Circle Shape (mm): D*H D=30i 200mm H=5i 20mm a a I 40*12a I 45*15a I 50*15a I 55*15a I 60*15a I 70*20a I 90*20a I 150*25a I 200*25a a a Square Shape (mm): a L*W*H a L=40i 600mm W=40i 600mm H=10i 50mm Other specifications of Silicon Carbide Ceramic Foam Filters are available on your request.

Pore Density (PP): 10-40 Porosity (%): 80-90 Operating temperature() : 1500 Bending Strength (MPa): 0.8 Compression Strength (MPa): 0.9 Thermal Shock Resistance(times/1100): 6
