Schneider Analog Output Module Twdam01ht Application: Industrial

Range of product: Twido

Product or component type
Analogue output number: 1

Analogue output type
Current: 4...20 mA
Voltage: 0...10 V
Analogue output resolution: 12 bits
I/O connection: Removable screw terminal block

Complementary
LSB value: 2.5 mV voltage
4 AuA current
Load type: Resistive
Load impedance ohmic
<= 300 Ohm current
>= 2000 Ohm voltage
Stabilisation time: 20 ms
Conversion time: 20 ms + 1 controller cycle time

Measurement error:
+/- 0.2 % of full scale 0...10 V 0...10 V at 25 A A C
+/- 0.2 % of full scale 4...20 mA 4...20 mA at 25 A A C
Temperature coefficient:
+/-0.015 %FS/A A C, analogue output type: current
+/-0.015 %FS/A A C, analogue output type: voltage
Repeat accuracy: +/-0.5 %FS
Non-linearity:
+/- 0.2 %FS, analogue output type: current
+/- 0.2 %FS, analogue output type: voltage
Output error: +/- 1 %FS
Output ripple: <= 1 LSB
Total error
+/-1 %FS, analogue output type: current
+/-1 %FS, analogue output type: voltage
Type of cable: Shielded twisted pair
Insulation between channel and internal logic

Photocoupler
Supply: External supply
[Us] rated supply voltage: 24 V DC
Supply voltage limits: 20.4 - 28.8 V
Current consumption: 40 mA at 24 V DC; 50 mA at 5 V DC
Marking: CE
Net weight: 0.085 kg

Environment
Dielectric strength: 500 V between the outputs and the supply circuit
Product certifications: CSA, UL
IP degree of protection: IP20
Ambient air temperature for operation: 0 - 55 A C
Ambient air temperature for storage: -25 - 70 A C
