Pvc Wpc Floor Skirting Board Foam Baseboard Extruder Extruder Machine

With years of experience and knowledge in this domain, we are engaged in manufacturing and exporting an extensive range of PVC WPC Floor Skirting Board Foam Baseboard Extruder Extruder Machine in Nantong, Jiangsu, China.

Product Description :
Model Number : BG-SJZ51
Raw material : PVC Powder, additives
Main Material : PVC and soft rubber side

Final Products
PVC baseboard usage :
1- Cover the ground floor and wall joints, better enable combine firm.
2- To reduce deformationod the wall, avoid damage to the collision force between the wall and floor.
3- Protect the wall to prevent carrying things.
4- Foot line easy clean when walking or doing clean wall soiling.

PVC baseboard mainly include 2 parts as below :
1- Formed or hard PVC skirtings.
2- PVC skirting with soft rubber edge.

PVC skirting board exreusion machine description
PVC plastic skirting board extrusion making machine include conical twin screw extruder, mould, water vacuum calibration tank, 3 oil colors printing machine, haul off machine, cutter and stacker.

Mould choose idea for PVC baseboard
Mould design 1 : mould die A + calibrator, already curved before printing
Mould design 2 : mould die A + calibrator + forming mould, will curve after printing by forming mould parts.

Technical parameter :
Specification Name : SJSZ51/105 Conical twin screw extruder
Diameter : 51mm and 105mm
Nitride Depth of screw and barrel : 0.5-0.7mm
Feeding Method : Two-screw feeding system
Inverter Brand : ABB
Extruder Main Motor Power : 18.5KW/AC
Extruder Speed Adjust Method : Transducer
