Good Quality Pedestrian Fork Lift Truck
Price:
Get Latest Price
In Stock
Product Overview
Key Features
experiences, we have been manufacturing and supplying a remarkable assortment
of Pedestrian Fork Lift Truck. Fitted with suitable stacking systems and
durable wheels, these trucks are largely demanded in various industrial sectors
for handling heavy weight. Our Pedestrian Fork Lift Truck is designed under the
guidance of veteran professionals by using optimum quality materials, in
compliance with international quality of standards and norms. We can also
customize these trucks as per the needs of the clients.
Features:
- High loading capacity
- Modular design
- Less in maintenance
Specifications:
Model | Hi-Lift-1005 | Hi-Lift-1008 | |||
| Capacity | 500 | kg | 800 | kg |
| at Load Center | 400 | mm | 400 | mm |
A1 | Overall length | 1265 | mm | 1272 |
|
A2 | Fork length+ | 750 | mm | 750 |
|
B1 | Wheel base | 915 | mm | 1000 |
|
C1 | Turning radius | 1085 | mm | 1206 |
|
D1 | Under Clearance | 75 | mm | 74 |
|
E1 | Overall Width | 840 | mm | 1054 |
|
E2 | Width of Fork Carriage | 825 | mm | 825 |
|
| Fork Spread | 775 | mm | 775 |
|
| Fork Width | 80 | mm | 80 |
|
G1 | Rear overthang | 170 | mm | 170 |
|
G2 | Front overthang | 180 | mm | 102 |
|
H1 | Standard colsed height | 1885 | mm | 1885 |
|
H2 | Standard lift height | 2700 | mm | 2700 |
|
H3 | Standard raised height | 3226 | mm | 3226 |
|
H4 | Standard free lift | 260 | mm | 260 |
|
| Width of Power unit | 825 | mm |
|
|
| Overall height (Excluding most) | 1345 | mm |
|
|
| Front wheel Track | 735 | mm | 940 | mm |
| Rear wheel Track | Central |
| Central |
|
| Load wheel (Front) | 203 x 102 | mm | 203 x 102 | mm |
| Drive wheel (Rear) | 254 x 102 | mm | 254 x 102 | mm |
| 90A a A A Stacking aisle | 1270 mm +Load Length |
| 1310 mm +Load Length |
|
| Travel speed - unladen | 5.5 | k/h | 5.5 | k/h |
| Travel speed - laden | 4.0 | k/h | 4.0 | k/h |
| Lift speed - unladen | 0.3 | m/s | 0.3 | m/s |
| Lift speed - laden | 0.22 | m/s | 0.22 | m/s |
| Lower speed - unladen | 0.25 | m/s | 0.25 | m/s |
| Lower speed - laden | 0.33 | m/s | 0.33 | m/s |
| Battery Voltage | 24 | volts | 24 | volts |
| Capacity at 5 hr. rate | 219 | AH | 219 | AH |
| Type of control | Electrical / Electronic |
| Electrical / Electronic |
|
LIFT SPECIFICATION | ||||
H2Maximum lift height (mm) | 2700 | 3000 | 3300 | 3600 |
TWIN MAST | ||||
H1Mast closed height (mm) | 1885 | 2035 | 2235 | 2335 |
H4Standard Free Lift (mm) | 260 | 260 | 260 | 260 |
H3Overall mast height (mm) | 3226 | 3526 | 3826 | 4126 |
Tilt forwardA a A A | Fixed Mast / 2A a A A | Fixed Mast / 2A a A A | Fixed Mast / 2A a A A | Fixed Mast / 2A a A A |
Tilt backwardA a A A | Fixed Mast / 2A a A A | Fixed Mast / 2A a A A | Fixed Mast / 2A a A A | Fixed Mast / 2A a A A |
Capacity at 500 load center (kg) | 500 / 800 | 470 / 710 | 460 / 680 | 420 / 660 |
