Pedal Load Cell - 8400-b001 - Application: Industrial
Share

Pedal Load Cell - 8400-b001 - Application: Industrial

Price:

Get Latest Price

Minimum Order Quantity :

1

In Stock

In Stock

Product Specifications

UsageUsed to measure the force applied to the pedal
Product TypePedal Load Cell
Voltage110-240 Volt (v)
MaterialStainless Steel
ApplicationIndustrial
ColorSilver
TypePedal Load Cell
Operating Temperature-40 to 120 Celsius (oC)
FOB PortHamburg
Sample AvailableNo
Main Export Market(s)Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa
Main Domestic MarketAll India

Product Overview

Key Features


With its flat construction this force sensor is specially designed to be fitted to a pedal. By this, the operator's forces for each respective action, for example brake tests, can be measured directly and the reaction of the vehicle or machine can be designated. This applies to real test drives, as well as in driving simulators. Due to the special construction of the membrane, it is irrelevant whether an upright or hanging pedal is concerned. The sensor is designed in a way that unavoidable lateral forces have as little impact on the measurement result as possible. Using a central internal thread on the control surface, various machine-related adaptor parts can be easily mounted. Because the pedal is convex-shaped on its surface, the pedal force sensor has a very rigid base plate and therefore can easily be applied to various geometrics. The mounting can even take place on a pedal with an elastomer covering.

With a height of only 17 mm, this sensor is particularly flat and, in its assembled state, does not interfere with the operation task of the pedal. Additionally, its diameter of less than 60 mm makes this sensor suitable for almost all forms of pedals. The sensor is screwed together in a safe and stable way with a suitable bracket which goes under the pedal. Due to various pedal designs, this bracket is not included in the delivery scope and has to be manufactured separately to fit to the pedal. The connection cable is specially protected, it sturdily holds using PG cable glands and is suitable for robots: Therefore lots of movements in realistic, dirty and damp areas are guaranteed. On the measurement membrane in addition to its stable mechanics several bridges formed by strain gauges protect the sensor from additional transverse forces. The operator provides, from personal factors such as foot position, habits or various shoes, inevitably off-centre forces on the operating part of the sensors, which need to be compensated.

Specific characteristics:
- Very flat design
- Insensitive to forces traverse to the operating direction
- Easy changeable, ergonomical operating plate
- Temperatures from -40 degC to 120 degC
- In combination with TRANS CAL 7281, can be used portably and independent of a network
- Option: available as dual range version

Please note:
The delivery limit is standard information. The exact delivery quantity you will learn with a specific request, because we individually respond to your wishes.
