Pcb Belt Conveyor For Ems Factory

With best industry reputation, we are engaged as manufacturer and exporter of an international class range of 1M PCB Handling Inspection Conveyor For EMS Factory in Shenzhen, Guangdong, China available with following details.

Our advantages:

a c Handles PCB Size from 1.95 inches to 27inches or More! (50mm - 685mm)
a c Custom Sizes Available
a c Quality Well Made Product
a c Sturdy Construction
a c Pass Through Mode or Inspect Mode
a c Adjustable Speed Control Conveyor
a c Flow: Left to Right
a c SMEMA Compatible
a c Smema Cable Included
a c Anti-Static Belts
a c Special Aluminum Guide Rail for smooth PCB movement
a c Includes 1yr parts warranty!

Technical Specification:
Brand Jwide
Model JW-808 1.0M Conveyor
Outer Dimension 1000*640*910mm
PCB Width 50~350mm
PCB Direction L to R or R to L
Speed 0~10000mm/min
Motor 1P AC220V 50/60HZ 15W
Power Supply 1P AC220V 50/60HZ
Rail length up to your request
Control System PLC
Foot switch standard
Lighting Option
SOP Rack Option
Platform material ESD Rubber Mat
Communication plug SMEMA Signal plug for up&down line
Weight Approx.52Kg
