Outdoor Access Point Wi Fi7 - Material: Metal

Product Specifications

Hardware Parameters

Chipset

IPQ9574+3*QCN9274

CPU frequency

Quad-core ARM Cortex-A73 at 2.2 GHz

Memory

2*512 MB DDR

Flash

128Mb NORflash

WIFI

4T4R 2.4GHz 802.11b/g/n/ax/be,3770Mbps

4T4R 5.8GHz 802.11AC/ ax/be,5760Mbps

4T4R 6GHz 802.11AC/ ax/be,11520Mbps

PD

IEEE 802.3 bt

PSE

IEEE 802.3af

Device Interfaces

2x RJ4510M/100M/1000M/10GWAN/LAN/Ethernet

1 x reset button

1x SFP+

1 x WPS button

WIFI Antenna

4x 5dBi Inner2.4G antenna

4x 5dBi Inner5.8G antenna

4x 5dBi Inner6G antenna

WIFI Features

Standard

802.11b/g/n/ac/ax/be

802.11b/g/nax/be, frequency 2.400 GHz to 2.4835 GHz

802.1la/n/ac/ax/be, frequency 5.150 GHz to 5.350 GHz && 5.470 GHz to 5.725GHz && 5.725 GHz to 5.850 GHz

802.11be ,frequency 5.925-7.125G

country-specific restrictions apply

Support all national channels

Modulation schemes

OFDM = BPSK,QPSK, 16-QAM, 64-QAM, 256-QAM, 1024-QAM, 4096-QAM

DSSS = DBPSK, DQPSK, CCK

TransferRate

EHT20: up to 2472Mbps 2.4G+5G+6G

EHT40: up to 2940Mbps 2.4G+5G+6G

EHT80: up to 5760Mbps 5G+6G

EHT160: up to 11520Mbps 5G+6G

EHT320:up to 11520Mbps6G

Max transmit power

2.4GHz:

11n max 30dbm (24dbm per chain)

11 ac max 30dbm (24dbm per chain)

11 ax max 30dbm (24dbm per chain)

5 GHz:

11n max 30dbm (24dbm per chain)

11lac max 30dbm (24dbm per chain)

1lax max 30dbm (24dbm per chain)

6GHZ

11be max 30dbm (24dbm per chain)

Software Features

General

Wireless main Protocols:

=IEEE 802.11a

=IEEE 802.11b

=IEEE 802.11g

=IEEE 802.11n

=IEEE 802.11ac

=IEEE 802.11ax

=IEEE 802.11be

=IEEE 802.11h(DFS)

=IEEE 802.11e(WMM)

=IEEE 802.11k/v/r

Wireless spec Features:

=Roaming

=Power Percent Adjustment

=Removing Low-RSSI STAs

=WIFI Optimization

=Beamforming

=Auto Channel

=320MHz Huge Frequency Width

=WPA/WPA2/WPA3 Security

=Guest SSIDs

=Separate Authentication for SSID

=Speed Limit for SSID

=Hidden SSID

=User Isolation for SSID

=Multi frequency integration

=WiFi timer

=WiFi access control

=MLO

=802.1x

=Multicast to Unicast

=short GI

=Beacon interval

=DTMl interval

=RTS Threshold

Network main Protocols:

=RFC0768 UDP

=RFC0791 IP

=RFC0792 ICMP

=RFC0793 TCP

=RFC0826 Ethernet ARP

=RFC0894 IP over Ethernet

=RFC0922 Broadcasting Internet Datagrams

=RFC0950 Internet Standard Subnetting Procedure

=RFC2516 PPP Over Ethernet (PPPoE)

=RFC1332 PPP Internet Protocol Control Protocol

=RFC1042 Transmission of IP Datagrams over IEEE 802 Networks

Network spec Features:

=IPv4/IPv6 dual stack

=Static/IPoE/PPPoE Connection Type

=IPv6 Stateless/Stateful

=Route and Bridge Mode

Other spec Features:

=Kick Off for Wireless User

=Block Internet for User

=Internet Time Schedule for User

=Speed Limit for User

=User Firewall MAC/IP/Port/URL filter for Data-Stream

=Night Mode(Light Control)

=Roaming Test

=Manual DNS

=VLAN

Management Features:

=WEB GUI

=Command Tool Telnet For Debug

=APP

=Local whole network management

=SSH

=HTTP/HTTPS

=Login Authentication

=NTP

=Settings Backup && Import && Recovery

=Firmware Local/Remote Upgrade

=System Reboot && Scheduled-Restart

=Network Self-Checking

=Fault Alarm

=Fault Collection

=Diagnostic Tools(ping/tracert/nslookup)
