Oil Drilling Mud Solids Control Mud Desilter
Price:
Get Latest Price
In Stock
Product Specifications
| Material | Steel |
| Dimensions | 1290X870X1920 Mm |
| Weight | 750Kg |
| Capacity | 200 M3/H |
| Pressure | 0.2-0.35Mpa |
| Separation | 15-44 Microns |
| Power | 0.5 Kw |
| Features | Solids Removal, Efficient Separation, High Capacity, Durable Design, Easy Operation, Low Maintenance, Precise Separation |
Product Overview
Key Features
We are engaged in manufacturing, distributing and exporting excellent quality Oil Drilling Mud Solids Control Mud Desilter in Cangzhou, Hebei, China.
Desilter
Condition:New
Application:Solids Liquid Separation
Place of Origin: Hebei, China (Mainland)
Brand Name: GSSY Solids Control
Model Number: ZCNQ-125X8
Part of Desilter:
Cone Dia. (mm): 125
Cone quantity: 8
Work pressure: 0.2-0.35Mpa
Capacity (m3/h): 200
Feeding pipe dia. (mm):150 (6inch)
Output pipe dia. (mm):200 (8inch)
Cone angle: 20 degree
Underflow Dia. (mm): 25
Separate point: 15 - 44microns
Part of shaker
Shake type: Auto oscillation motor IBT4
Vibration Mode: Linear motion
Vibration speed (rpm):1450
G-force(kn): 0-10
Power (kw):0.5
Screen mesh: upper 120 below 40
Screen size (mm):1100x600
Dimension (L*W*H): 1290x870x1920 mm
Weight: 750kg
Certification: ISO
Warranty: One year
After-sales Service Provided: Engineers available to service machinery overseas
Model Number: ZCNQ-75X16
Part of Desilter:
Cone Dia. (mm): 75
Cone quantity: 16
Work pressure: 0.2-0.35Mpa
Capacity (m3/h):240
Feeding pipe dia. (mm):150 (6inch)
Output pipe dia. (mm):200 (8inch)
Cone angle: 15 degree
Underflow Dia. (mm): 10
Separate point: 20-44microns
Part of shaker
Shake type: Auto oscillation motor IBT4
Vibration Mode: Linear motion
Vibration speed(rpm):1450
G-force(kn): 0-10
Power (kw): 0.5
Screen mesh: upper 120 below 40
Screen size (mm):1100x600
Dimension (L*W*H): 1600x1000x1800 mm
Weight: 780kg
Certification: ISO
Warranty: One year
Desilter
Condition:New
Application:Solids Liquid Separation
Place of Origin: Hebei, China (Mainland)
Brand Name: GSSY Solids Control
Model Number: ZCNQ-125X8
Part of Desilter:
Cone Dia. (mm): 125
Cone quantity: 8
Work pressure: 0.2-0.35Mpa
Capacity (m3/h): 200
Feeding pipe dia. (mm):150 (6inch)
Output pipe dia. (mm):200 (8inch)
Cone angle: 20 degree
Underflow Dia. (mm): 25
Separate point: 15 - 44microns
Part of shaker
Shake type: Auto oscillation motor IBT4
Vibration Mode: Linear motion
Vibration speed (rpm):1450
G-force(kn): 0-10
Power (kw):0.5
Screen mesh: upper 120 below 40
Screen size (mm):1100x600
Dimension (L*W*H): 1290x870x1920 mm
Weight: 750kg
Certification: ISO
Warranty: One year
After-sales Service Provided: Engineers available to service machinery overseas
Model Number: ZCNQ-75X16
Part of Desilter:
Cone Dia. (mm): 75
Cone quantity: 16
Work pressure: 0.2-0.35Mpa
Capacity (m3/h):240
Feeding pipe dia. (mm):150 (6inch)
Output pipe dia. (mm):200 (8inch)
Cone angle: 15 degree
Underflow Dia. (mm): 10
Separate point: 20-44microns
Part of shaker
Shake type: Auto oscillation motor IBT4
Vibration Mode: Linear motion
Vibration speed(rpm):1450
G-force(kn): 0-10
Power (kw): 0.5
Screen mesh: upper 120 below 40
Screen size (mm):1100x600
Dimension (L*W*H): 1600x1000x1800 mm
Weight: 780kg
Certification: ISO
Warranty: One year
