Newgen 15 Kva Touch Ups

Price:

Get Latest Price

In Stock

Product Specifications

Power	15 KVA
Technology	DSP based
Output	Pure sine wave
Charger	IGBT based
Connectivity	Ethernet
Display	Touchscreen
Transformer	Isolation
Features	Pure Sine Wave, Touchscreen display, High efficiency, Remote monitoring, Reliable power, Cost savings, High power factor, Isolation transformer

Product Overview

Key Features

15 KVA to 40 KVA Touch UPS

UTL has developed DSP technology based newGEN touch Online UPS to meet the energy efficiency requirement of the IT industry through advanced PFC Technology. The purpose of PFC (Power Factor Corrector) is to correct the phase angle of Input AC current in such a way that it harmonizes in the angle of input ac voltage making input power factor very close to unity. This harmony of phase angles of input current and voltage reduces the difference between Watt and VA consumption, on which the commercial energy invoices are raised these days, thus comprehensively reducing the electricity expenses of the user.
With a Touch Screen Color Display integrated on its front the user can now easily check on the Input, output & Battery Parameters, On / Off & other Switches, Load Level & even the Battery Level Bar Graph.
AVAILABLE IN
THREE PHASE IN SINGLE PHASE OUT
THREE PHASE IN THREE PHASE OUT

Pure Sine Wave Output
Option for Ethernet connectivity
IGBT based charger
Isolation transformer
Typical Applications

Pure Sine Wave Output

UTLs newGEN PFC online UPS is a MicroController, High Frequency PWM Technology Based True Online Double Conversion UPS System with IGBTs or MOSFETs at the Inverter Stage thus provides pure Sine wave output with high reliability and Efficiency. Making the newGEN PFC online UPS totally fit for running heavy loads like ACs, Industrial Motors and Pumps at gas stations etc. Even highly sensitive medical equipments such as life support systems work flawlessly with this ups.
[Top]

Option for Ethernet connectivity

The newGEN PFC online UPS manufactured by the house of UTL has the option to connect to the internet via a built in Ethernet port at the back of the ups. When connected to the internet UTLS newGEN PFC online UPS lets its user enjoy the freedom of monitoring its working from any where he likes may he be in any part of the world and be using any kind of internet device.
[Top]

IGBT based charger

UTLs newGEN PFC online UPS turns out to be more like a savings account for the user. Being IGBT based this ups has a power factor of a whopping 0.9 where as it is just 0.7 in a parallel SCR has based ups. Because of having a power factor which is relatively higher the newGEN PFC online UPS helps to save upto 40% more power which in turn leads in large savings during its period of use.
[Top]

Isolation transformer

newGEN PFC online UPS has an inbuilt isolation transformer, this helps in giving a better impedance match of a critical load to an electrical circuit. Totally fit for use in hospitals the isolation transformer in the newGEN PFC online UPS protects the sensitive equipments. UTLS newGEN PFC online UPS suits Indian Power Conditions to its best making it installable anywhere from a hi-tech city to any village in India
[Top]

Typical Applications

DP equipment and systems (computers, printers, monitors etc.)
Process controls, testing & measuring instruments.
Medical & electronics health-care equipments & Life-support systems in hospitals.
Security lighting & Control centers
Safety systems in power stations
Audio-visual equipments.

SPECIFICATIONS

Power Rating	15 KVA to 40 KVA
INPUT
Voltage Range	400V +/- 20%
Frequency	50 Hz +/- 5%
Input Power Factor	>0.92
Charger Topology	BUCK-IGBT
OUTPUT
Voltage	220 V
Power factor	0.8, UPF
Frequency	50 Hz
Wave Form	Pure Sine Wave
Transient Response	<8(10%~90% Linear Load)
Voltage Harmonic	< 3 % (Linear load)
Overload Capacity	100 to 110%:5 min, 110 to 120%:2 min, 120 to 150%:30 sec, 150 to 300%:20 to 30 msec, >300%:immediate
Crest Factor	3:1
Voltage regulation	+/- 1%
Frequency Regulation	+/- 0.05 Hz
Receptacle	BS546 , Screw terminal
AUDIBLE WARNING
Battery back up ending	Intermittent
Overload	Continuous
DISPLAY
LED	UPS On # Battery High/Low # Overload-R,Y,B # O/P High/Low-R,Y,B # Charging On # Mains High/Low-R,Y,B
LCD (20X4)	Input, Output & Battery parameters # Load Level # Working Mode # Fault Status
Touch Screen Color Display (optional)	Input, Output & Battery parameters # Load Level # Working Mode # Fault Status
PROTECTIONS
Parameters	O/P High/Low-R,Y,B # Overload-R,Y,B # O/P ShortCircuit # O/P High/Low-R,Y,B # Battery Over/Undervolt
INTERFACE
Db9	RS232 / USB Port, SNMP (Optional)
OTHERS
Battery Start	Standard
Cabinet wheels	Standard
Extended battery charging	Optional
Static by pass	Optional / Default rotary switch
OVERALL
Efficiency (AC - AC)	>90% (full load)
Transfer time	0 msec
Temperature	0 to 45 *C
Humidity	5 - 95 % (Non condensed)
