Fep Encpsulated Silicon N Series Power Generator

N Series Power Generator

Features

Cummins PT fuel pump, step Timing control injectorHolset turbocharger, Pulse tuned exhaust manifold, stainless steel exhaust flexible couplingRadiator or heat exchanger, coolant inhibitor, Low temperature after cooling (LTA)Articulated pistonGear train with spur gearsPlate type lube oil coolerSpin on filters fuel, lube oil and coolantDry type replaceable paper element air cleaner with restriction indicatorFlywheel housing and flywheel to suit single bearing alternatorStarting motor electricElectronic control panel with electronic gobvernor (ECPG)Engine protections (Shutdown) High water temperature / Low lube oil pressure / Overspeed
Options
Engine: Heavy duty air cleaner, Heat exchanger, Lube oil / Coolant heater with thermostatic switchAlternator: PMG excitation, RTDs, BTD, Space heaterControl Panel: AMF control panel, Battery charger, Remote / Auto
start panel, Auto / Manual synchronizing panel, Audio / Visual
annunciation for faults






Genset Model

Engine Model

BHP Rating at 1500 RPM

kVA (Prime)

Bore (mm)

Stroke (mm)

Disp. (ltrs)



C 320 D5 P

NTA 855 G2-I

308

320

140

152

14.0



C 380 D5 P

NTA 14 G3

450

380

140

152

14.0
