Lr Type 0.47-6800uf 6.3-50v 1000-2000hrs Application: Residential

LR Type 0.47-6800uF 6.3-50V 1000-2000hrs LR Series Low Impedance FEATURES Used in communication equipments switching power supply  industrial measuring instruments etc Load life 1000-2000 Hrs Safety vent construction design  RoHS Compliant SPECIFICATIONS Item Performance Characteristics Operating Temperature Range -40 to + 105C Rated Voltage Range 6.3 to 50 VDC Capacitance Range 0.47 to 6800 pF Capacitance Tolerance 20%(120Hz +20C) Leakage Current (+20C max) 10.01 CV or 3 (pA)After 1 minutes whichever is greater measured with rated working voltage applied Dissipation Factor(tan at 20C 120Hz) Working Voltage (VDC) 6.3 10 16 25 35 50 63 100 D.F. (%) max 18 16 14 12 10 9 9 8 For capacitance > 1000pF add 2% per another 1000pF Low TemperatureCharacteristics (at 120Hz) Impedance ratio max Working Voltage (VDC) 6.3 10 16 25 35 50 63 100 Z-25C / Z+20C 4 3 3 3 3 3 3 3 Z-40C / Z+20C 8 6 4 3 3 3 3 3 For capacitance > 1000pF add 0.5 per another 1000pF for -25C / +20C add 1 per another 1000pF for -40C / +20C Load Life Test conditions D Life hours Duration time :as right 5-6.3 1000 Ambient temperature :+105C 8 2000 Applied voltage :Rated DC working voltageAfter test requirement at +20Capacitance change :20% of the initial measured valueDissipation factor :200% of the initial specified valueLeakage current :The initial specified value Shelf Life Test conditionsDuration time :1000 HrsAmbient temperature :+105CApplied voltage :NoneAfter test requirement at +20C :200% of the initial specified valuePre-treatment for measurements shall be conducted after application of DC workingvoltage for 30 minutes Other JISC-5141 EIAJ RC-2372 MULTIPLIER FOR RIPPLE CURRENT VS. FREQUENCY CAP (pF) \ Frequency (Hz) 50 (60) 120 400 1K 10K 50K~100K CAP10 0.47 0.59 0.76 0.85 0.97 1 10<CAP100 0.52 0.62 0.80 0.89 0.97 1 100<CAP1000 0.58 0.72 0.84 0.90 0.98 1 1000<CAP 0.63 0.78 0.87 0.91 0.98 1
