Liquid Nitrogen Container Yds-1-30

The Liquid Nitrogen Container YDS-1-30 is small capacity, which are designed for transferring or transporting biological samples stored by manual work, especially for customers in the mountainous area, featuring portable, less static evaporation loss mass of liquid nitrogen and being economical in usage,including 1 canisters
Model Unit YDS-1-30
Capacity L 1.0
Empty Weight kg 2.0
Full Weight kg 2.8
Neck Diameter mm 30
Outer Diameter mm 180
Height mm 320
Static Evaporation Loss Mass L/d 0.06
Static Holding Time d 16
Canister Outer Diameter mm 26
Canister Height (single/double) mm 120
Number of Canistersi ni n 1
Straw Holding Capacity(single level) 0.5ml 60
0.25ml 120
Straw Holding Capacity(double level) 0.5ml a 0.25ml.

Main Features:

a High-strength aluminum alloy structure, light empty weight
a Hinged handle (except YDS-5-200) is portable
a The lockable device can be installed to the container lid upon customers' requirement so as to protect biological samples stored (limit for 30mm, 50mma 80mm calibers)
a Encoding system is applied on canisters for easy recognition and convenient accessing of samples
a More than 5-year vacuum quality guarantee is ensured with the multi-layer thermal isolation design
