Kcdl5y/kctdl5y Petroleum Centrifuge Speed: 5000 Rpm

Noise Level : a 65dBi Ai 5000rpm
Max RCF : 4250A g
Chamber diameter : I 500mm 3850A g
Max Capacity : 8A 100ml
Outer Dimensions : 825A 625A 910mm, 24A 10ml
Timer : 1mini 99min
Package Dimensions : 930A 730A 1010mm, 1mini 99min
Revolutions/min : A 20r/min
Net weight : 108kg A 20r/min
Voltage : AC 220A 22V 50Hz 15A
Gross weight : 128kg
VC 220A 22V 50Hz 15A
Power : 1500W / / 850W

Large LCD and LED display (options for the users), able to display rotor model, RPM, timing, temperature, RCF, acceleration/deceleration rate and error message etc.
Adopted ring shape heater to facilitate rapid and even heating, equipped with temperature control and maintenance functions to fulfill the temperature requirement of petroleum industry for centrifuges.
Adopted large torque frequency variable motor to enable stable and rapid acceleration and deceleration, long life and maintenance free, low noise level, stability greatly enhanced.
Centrifuge tubes made by special technology to prevent rupture during operation. It has been widely used in Daqing oil field.
Error auto diagnosis system able to detect errors including over speed, over heat, imbalance and door lid self-lock etc, and window display the error messages to enhance the safety features of the equipment.
Easy to operate:
Controlled by computer, touch screen, able to set up rotor model, RPM, RCF, temperature, timing, acceleration/deceleration rate, and modify these parameters during operation, user friendly.
