Industrial Ethernet Switch - Ip30 Metal Case For 19" Rack, 24 Rj45 Fast Ethernet Ports, 10/100m Support, Dc/ac Power With Low Consumption Design

Our offered range of Industrial Ethernet Switches is available with following features :-

1.Support 24pcs RJ45 fast Ethernet ports
2.Support IEEE802.3/802.3u/802.3x
3.Support 10/100M, half/full duplex, MDI/MDI-X
4.Support broadcast storm shield
5.DC110/220V or AC100/240V 3 bits terminal block power input
6.No fan, low consumption design
7.IP30 protection, metal shell, 19" 1U standard rack
Specification:
Technology:
Standard: IEEE802.3, IEEE802.3u, IEEE802.3x
Flow control: IEEE802.3x
MAC address: 8K
Interface
RJ45 Ports: 10/100BaseT(X) auto connection, Full /Half duplex or force work mode, and support
MDI/MDI-X connection
LED indicator: PWR, SYS, Link
Power:
Input power: 110~220VDC (100~300VDC)
Or 100~240VA C (85~264VAC)
Input current: 0.25A (@110VAC/VDC)
Connector: 3 bits terminal block
Environmental
Operating Temperature: -40 to 75A C
Storage Temperature: -45A C to 85A C
Relative Humidity: 10 to 95% (non-condensing)
Mechanical
Shell: IP30 protection, metal case
Installation: 19a 1U rack
WA HA D: 441.6mmA 44.6mmA 206.9mm

Approvals:-
EMI: FCC Part 15, CISPR (EN55022) class A&
EMS: EN61000-4-2 (ESD), Level 3
EN61000-4-3 (RS), Level 3
EN61000-4-4 (EFT), Level 3
EN61000-4-5 (Surge), Level 3
EN61000-4-6 (CS), Level 3
EN61000-4-8, Level 5
Shock: IEC 60068-2-27
Free Fall: IEC 60068-2-32
Vibration: IEC 60068-2-6
