Imported Shredder Machine (Heavy Duty Industrial Shredder Machine)

Imported Sredder Machine Technical specification

Machine WPL 3000 / 800 A A A AcA A A A A A A A 280 kW ( Powerline )

Standard funnel volume Approx. 6,5 A A A AcA A A A A A A A 15 mA A A A A A A A - depending on hopper dimensions

Loading height Min. 2.700 mm incl. 800mm base frame

Operating width 3.000 mm

Rotor diameter 800 mm Main motor 280 kW

Hydraulic motor ( Wing RAM ) 11 kW

No. of blades 116 pieces

Blade type / Blade size 100 x 100 mm cutting knives octagonal, four or eight times usable, thickness 48mm

First counter knife Consisting of 7 parts, four times usable

Second counter knife (optional) Consisting of 7 parts, four times usable

Screen thickness 15mm strong inserts, 4 parts, Creusabro, 400HB

Screen perforation Screen 80 mm round hole shape, no tolerance screen

Color WEIMA Standard RAL 2002 / 7016

Connected load 400 V +/- 5 % / 50 Hz

Noise emission in idle run ca. 85 db(A)

Noise emission under full-load condition > 90 db(A) depends on material

Weight Approx. 40.000 kg
