Ieee802.3at Gigabit Poe Injector - 44~57v Dc Input, 45w Ultra High-power Output, 4kv Surge Protection, Ip65 Weatherproof Option, Led Monitoring

Being the most respected organization guided by experienced and knowledgeable professionals, we are the famous Exporter, Manufacturer & Distributor of IEEE802.3at Gigabit PoE Injector (DC Input) in Shanghai, Shanghai, China.
The PSE-M01-GD0DC-S is an IEEE802.3at complaint high-power PoE injector with DC power input for power over Ethernet application.
Connecting with 44~57Vdc input power, the PSE-M01-GD0DC is ideal for powering PoE devices such as WLAN access points, IP cameras, and other PD devices.
Integrated with protection circuit, PSE-M01-GD0DC-S also provides 4KV lighting & surge protection to the Ethernet port.

FEATURES
* G.bit Support a no data packet loss in 100Meters CAT5e G.bit @30W Output
* Standard Compliance a fully compliant with IEEE 802.3at
* Advanced Auto-Sensing Algorithm a standard IEEE 802.3af/at auto-sensing algorithm. Hi-Power output only at PD is classified at Class4.
* Concise LED Displays a real-time monitoring input power LED and PoE LED, indicating delivering power, over-load, short-circuit, and detection fail.
* 4KV Surge & Light Protection a with surge & light protection.
* 45W Ultra High-Power for Class#5 PD a use with 56V PSU to support 45W Ultra High-power output function.
* Aluminum Housing with DIN-Rail Mounting a optional DIN-Rail Mounting Kit
* Outdoor Enclosure a optional IP65 weather proof enclosure is available for order

SPECIFICATION
* Data Ratei 10/100/1000Mbps
* Input Power Voltagei 44 to 57 Vdc
