Hydraulic Copy Lathe Turning Attachments

We are considered as a reputed firm, we are engaged in manufacturing, supplying and exporting a wide range of Hydraulic Copy Lathe Turning Attachments in Faridabad, Haryana, India. Implementing latest technology with in our manufacturing facility, we have been able to offer best quality Hydraulic Copy Lathe Turning Attachments. These Copy Lathe Machine can be mounted at rear or front of a lathe and can be easily operated by even semi-skilled personnel. They are rigorously tested to render hassle free longer service. Our range of hydraulic copying attachment is an ideal and cost effective replacement for manually operated production on any lathe.

Technical Specifications:-
Model : 5660, 7090, 1014, 1020
Stroke of Tracing , Slide in mm : 60, 90, 140, 200
Minimum centre Height from top of . cross slide in mm : 105, 115, 155, 155
Max. Dia of Round Master in mm : 90, 90, 200, 200
Max. Length of Master in mm : 1000, 1000, 2000, 2000
Hydraulic Working Pressure in Kg/Cm2 : 18, 18, 14, 14
Pump Output in Ltr / Min : 8, 8, 16, 16
Power Pack H.P : 1, 1, 1.5, 1.5
Theoretical thrust in Kg : 190, 300, 470, 470
Recommended toll sank in mm : 20 x 20, 25 x 25, 32 x 32, 32 x 32
"Specifications and illustrations are subject to change without prior notice."
