Gx-1v Video Optical Converter

The GX-1V Video Optical Converter is a fiber optic digital multiplexer for transmitting 1 channel of high quality, uncompressed digital video. Applications for this product include CCTV, video surveillance, homeland security, ITS and etc.

Technology Characteristics
a Transport 1 channels of High quality video over one optical fiber cable
a Exceed RS250C Medium Haul Specification for DG, DP and SNR
a 8 MHz video bandwidth, Compatible with NTSC, PAL and SECAM
a Uncompressed video, 8 Bit digital encoding/decoding
a Transmission of 2 channels of any directional audio
a Provide 2 channels of bi-dir data compatible with RS232, RS422/ RS485
a Easy installation and adjustment free
a Transmission up to 20Km or 40Km or 60Km

Specifications

Indicators :
a Power, Optical Link Status
a Video Signal, Audio status, Data traffic

Video :
a Format: PAL/NTSC/SECAM
a Video Signal: 1Vp-p, 75IC
a Digitization: 8bits, 15M Sample
a Bandwidth 8 MHz
a DG <1%
a DP <0.5
a SNR >63dB(weighted)
a Connectors: 4 BNCs

Audio :
a Channel: 1~2, Bi-dir
a Audio Input: unbalanced, 600Ohms
a Digitization: 16bit@48k
a Frequency: 10Hz to 20KHz
a SNR: >70dB
a Connector: RJ45

Data :
a Channel: 1~2, Bi-directional
a Data Rate: 0~~23.04Kbps/channel
a Selectable RS-232/RS-422/RS-485
a Connector: RJ45
