Gsm Gps Combo Magnetic Mount Antennas

We are prestigious manufacturer & supplier of GSM GPS Combo Magnetic Mount Antennas in Bengaluru, Karnataka, India. These are manufactured from the reliable and high grade raw material. Further, these are similar to the GSM modules. We offer these at industry leading prices and also customize the packaging of these products as per clients needs.

Specifications:-

ModelLWC-GSM_GPS(Combo)-MM-28
Frequency Range (MHz)1575 +/- 5MHz
Gain (dBi)> 3.0 (with LNA)
VSWR< 1.5
PolarizationRHCP
Axial Ratio3dB Typical
Impedance50
Bandwidth+ 5MHz
Electrical Specifications (LNA / Filter)
LNA Gain without cable28 + dB (Typical)
Noise Figure1.5dB
DC Voltage3 i? 5 V
DC Current5 -15 mA
Power Consumption4.8mA@2.7V; 6mA@3.3V; 10.43mA@5V
GSM Antenna Specifications
Frequency824 i? 960 MHz and 1710 i? 2170 MHz
VSWR< 2.5
Impedance50
Mechanical Specifications
Cable RG174 / 3m
ConnectorAs required
HousingBlack
Environmental Specifications
Working Temperature-40 to 85 degrees centigrade
Humidity55% to 75% RH
WaterproofIP65
Dimensions (mm)80 x 10.5mm
