Elsa Supercombinata Boring Machine - 40 Mm X 2200 Mm Diameter, 1800 W Ac Motor, Unlimited Longitudinal Stroke, Green Color, New Condition

DIAMETERS Boring bar diameter: A, 40 mm x 2200 mm In line boring: A, 42 a 250 mm External line boring: Extra kit Internal welding: A, 42 a 250 mm Facing of orthogonal planes: Extra kit ROTATION MOTOR AC motor: Single phase Power at rated speed: 1800 W Output torque at the bar: 290 Nm with 120 rpm 1A speed: max 100 rpm (170 Nm) 2A speed: max 340 rpm (50 Nm) FEED MOTOR Gear motor: DC Power at rated speed: 90 W Max speed: 11 rpm Feed system: Electromechanical Feed: Manual/Automatic WELDING TECHNOLOGY Spiral: Continous with variable step Welding machine: Compatible with MIG/MAG wire with EURO connector LONGITUDINAL STROKE Unlimited: With 250 mm pitch ELECTRONIC CONTROL PANEL Voltage: 220/240 V (50/60 Hz) Main switch: Available Emergency switch: Available Inverter feed: RH/LH Inverter rotation: CW/CCW Speed regulator: Rotation/Feed Electrical absorption: 2000 W Control panel 110/120 V: Upon request DIMENSIONS Length: 545 mm Width: 220 mm Height: 380 mm Weight central unit: 34 Kg STANDARD EQUIPMENT Qty 1 - Main unit Qty 1 - Boring machine stand Qty 1 - Electronical control panel Qty 1 - Control panel holder Qty 1 - Cable control panel /machine Qty 1 - Power cable 220 V Qty 1 - Boring bar A, 40x2200 mm Qty 1 - Boring bar extension 420 mm Qty 1 - Pivot Qty 1 - Tool holder for boring d. 100-250 mm Qty 1 - Special tool holder LH A, 12x40 mm Qty 1 - Tool holder LH A, 12x40 mm Qty 1 - Tool holder LH A, 12x60 mm Qty 1 - Tool holder right RH A, 12x100 mm Qty 1 - Box with 10 cutting inserts Qty 2 - Main bar support Qty 2 - Additional support Qty 1 - Telescopic shaft for welding Qty 5 - Diffusor extension 35 mm Qty 4 - Short gas nozzle Qty 4 - Long gas nozzle Qty 5 - Short contact tip A, 0.8 mm wire Qty 5 - Long contact tip A, 0.8 mm wire Qty 1 - O-ring for welding shaft 100x5 mm Qty 1 - Centring system for through holes Qty 1 - Telescopic gauge up to A, 250 mm Qty 1 - Dial gauge Qty 1 - Dial gauge support Qty 1 - Set of wrenches Qty 1 - Screws and bolts EXTRA KITS BORING REDUCTION KEP00187 A 22 - 44 mm (0,87a - 1,73a ) KEP00188 A 32 - 70 mm (1,26a - 2,76a ) FACING KES00186 A 48 - 255 mm (1,89a - 10,04a ) OD MACHINING KEL00202 A 100 - 200 mm - D. 200 mm (3,94a - 7,88a )
