Drilling And Tapping Machinery For Industrial Use

Our firm is viewed as a reliable name of the current market which is committed in Manufacturing, Distributing, Supplying and Trading a best grade array of Drilling and Tapping Machinery in Ahmedabad, Gujarat, India that is made from preeminent quality crude materials and latest technologies and machinery.

Model LG-13 LG-16A LG-25B LG-25A M-360
Specifications FL FL FL FL BM
Drilling Capacity 13 20 25 25 6
Spindle Taper MT2 MT2 MT3 MT3 JT1/ER16(Opt)
Spindle Travel 80 100 120 140 60
Spindle rpm 520-2230 240-2840 230-1910 230-1910 5000.6800. 8400
No. of S. Speeds 4 9 9 9 3
Swing 360 360 460 460 310
Column Diameter 80 80 92 HV 102 80
Table Diameter 360 360 400 420
Base Size 300x500 300x500 335x530 380x600 200x380
Dist. Spindle to Table Max. 450 450 720 630 ...
Dist. Spindle to Base
Max. 620 620 920 930 230
Min 100
Motor 0,5 1 1.5 2 0.5
Overall Height 1070 1070 1500 1540 730
Weight 75 90 140 190 48
