Digital Temperature Indicator For Oil And Winding Transformer

We are engaged in offering excellent quality Digital Temperature Indicator For Oil And Winding Transformer to our valuable clients.
XMT-288F(C)series digital temperature indicators are specially designed products for oil and winding temperature indicators,and it can used with BWR series and BWY series.The main function of XMT-288F(C) is remote measurement of the power transformer and ouput the control signals meanwhile.
This series product includes XMT-288F,XMT-288FC,and so on.The XMT-288F does not have the function of output signals,and XMT-288FC can output the standard signals that include 0-5V,1-5V or 4-20mA.XMT-288FC-II has RS-485 and RS-232 port that can be linked to the computer directly.XMT-288FC-III is used to winding temperature indicators.

XMT-288F(C) series digital temperature indicator main technical data:
Working temperature:-10 a `~50a ,relative humidity:i 85%
Measuring range:same as oil and winding temperature indicators
Accuracy:+/- 1%
Display:0.8a x7 nixie tube
Resolving power:0.1a

Control capability:
1)Setting range:all span
2)Contact ouput:both high or low limit alarming with set of normally open or close contacts
3)Rated power:AC250V/3A
Input signal:Pt100(three-wire system)or 4-20Ma(two-wire system)

Output signal:
1)DC 0-5V,1V-5V,or 4Ma-20Ma
2)RS485 or RS232 computing port
Note:It allows the load resistance 250~350IC for DC 4-20mA output.
Power supply:AC220V/50Hz
Power dissipation:6W
Overall dimension:(160Wx80Hx134L)mm
