Name: DEIF ML150-AGC150 ADVANCED GENSET CONTROLLER
Price: 1 INR
Availability: InStock

Deif Ml150-agc150 Advanced Genset Controller - 3-phase Measuring Circuits, Automatic Multiple Diesel Generator Changeover, Energy Management Integration

Price: 1 INR / Piece

Get Latest Price

Minimum Order Quantity :

1 Piece

Brand Name :

Deif

In Stock

Product Specifications

Drive Type	Electronic governor and actuator compatible
Mounting Type	Flush panel mounting
Speed Range	Engine speed measurement up to 6000 RPM
Sensor Type	Support for analog and digital sensors
Frequency	50/60 Hz (auto detection)
Screen Size	3.5 inch color TFT display (320A--240 pixels)
Control Type	Microprocessor based digital control
Connectivity Type	Ethernet (Modbus TCP/IP), USB, CAN bus (CANopen & J1939), RS485 (Modbus RTU)
IP Rating	IP65 (front), IP20 (rear)
Remote Control	Yes
Weight	Approx. 1.2 kg
Phase	Three phase or Single phase
Processor Type	32-bit ARM Cortex microprocessor
Load Capacity	Rated for up to 20 paralleling gensets
Application	Advanced controlling and synchronisation of gensets, protection and monitoring
Features	Auto mains failure, load sharing, remote monitoring, easy commissioning, advanced protection features
Cable Length	Up to 10 meters (with recommended cable type for display unit)
Automation Grade	Automatic
Material	Polycarbonate, ABS plastic front with metal rear panel
Power	24 V DC (18 to 36 V DC range)
Temperature	Operating: -25AdegC to +70AdegC
Voltage	Fuel, auxiliary and power supply: 24 V DC, Digital inputs: 24 V DC, Relay outputs: 250 V AC/30 V DC
Supply Ability	100 Per Month
Delivery Time	7 Days
