Crlw Single-stage Single-suction Vertical Centrifugal Pump

The type Crlw Single-Stage Single-Suction Vertical Centrifugal Pump is single-stage single-suction vertical volute centrifugal clear water pump. It is widely used to handling circulation water for power stations, mining drainage as well as water supply & drainage of municipal facilities and farmlands. It is provided for delivering clear water without solid particles or other liquid which is physically and chemically similar to clear water. The highest temperature of the liquid must below 50a .
Performance range
Capacity Q: 1.6~6.8m3/s
Head H: 13.1~63m
Instruction of pump type
For example CRLW44P Left-11JA
CR: Company Codei means produced by CREDO PUMP.
LWa Large scale vertical single-stage single-suction volute centrifugal pump.
44a inlet diameter 44 inch.
Pa the pump foundation plate is changed
Lefta the rotation of impeller is clockwise looking from the motor to the pump.No indication when the rotation of impeller is counter clockwise.
22a the number obtained from the pump specific speed divided by 10.
Ia Difference of impeller in construction, indicating a , a a a .
Aa Outer diameter of impeller has bee changed. Indicating A, B, Ca a .
The direction of rotation
The rotation of pump rotor is counter clockwise looking from the motor to the pump. Indicating a lefta in pump type if you require the rotation of pump rotor is clockwise .Both rotation mode have same performance data.
Parts range
Pump, Motor, Foundation plate and Mounting resistant cushion.
