Cpm Fully Refurbished Biomass Pellet Mill - High-quality Steel, 2x2x2 Meter Design, Touch Screen Display, 50 Hz Electric Power | Suitable For Wood, Biomass, Feed, 3000 Kg Weight

All of the Pellet Mill is fully refurbished to a high standard. Each mill is run in at our factory to ensure we deliver a high-quality Mill for long lasting pelleting production


CPM 7900
Make: CPM
Type: 7930 - 7932 - 7936
Year: 2012 - 2013 - 2014 - 2016 - 2018
Die Diameter(mm): 762 - 825 - 915
Die Width (mm): 94 - 115 - 156 - 180 - 210 - 240 - 275 - 313 - 356
Die Surface (cm2): 2250 to 10230
Die Speed (RPM): 150 & 210
Die Linear Speed (mtr/sec): 5.9 - 6.4 - 7.1 - 8.3 - 9.0 - 10.0
Electric Motor (kW): 315 - 355 - 400
Capacity: 4 TPH to 15 TPH
Suitable for: Wood - Biomass - Feed


CPM 7700
Make: CPM
Type: 7722- 7926 - 7930
Year: 2010 - 2011 - 2012 - 2014 - 2016 - 2018
Die Diameter(mm): 572 - 673 - 762
Die Width (mm): 60 - 94 - 156 - 180 - 210 - 240
Die Surface (cm2): 1078 to 5027
Die Speed (RPM): 150 & 210
Die Linear Speed (mtr/sec): 4.5 - 5.9 - 5.3 - 6.3 - 7.4
Electric Motor (kW): 160 - 200
Capacity: 3 TPH to 10 TPH
Suitable for: Wood - Biomass - Feed

CPM 3000
Make: CPM
Type: 3020 - 3022
Year: 2010 - 2011 - 2013 - 2015 - 2016 - 2017
Die Diameter(mm): 508 - 572
Die Width (mm): 60 - 113- 156
Die Surface (cm2): 1078 to 2490
Die Speed (RPM): 210 & 270
Die Linear Speed (mtr/sec): 5.6 - 6.3 - 7.2
Electric Motor (kW): 90 - 132 - 160
Capacity: 2 TPH to 7 TPH
Suitable for: Wood - Biomass - Feed

CPM 2000
Make: CPM
Type: 2016
Year: 2009 - 2010 - 2012 - 2014 - 2016
Die Diameter(mm): 407
Die Width (mm): 57 - 83 - 116
Die Surface (cm2): 729 to 1483
Die Speed (RPM): 212 & 272
Die Linear Speed (mtr/sec): 4.5 - 5.7
Electric Motor (kW): 90
Capacity: 1 TPH to 3 TPH
Suitable for: Wood - Biomass - Feed
