Continuous Stirred Tank Reactor - Adjustable Flow Rota Meter, Compressed Air Circulation, Automated Stirring System, Integrated Safety Features, Pressure Regulation Mechanism

Specification:
CONTINUOUS STIRRED TANK REACTOR (C.S.T.R.) APPARATUS
Provided to measure the individual flow of Chemicals. The flow rate can be adjusted by operating the needle valves provided on respective Rota meter. The compressed air is used for circulation of feed. The CSTR is fitted with stirrer for proper mixing. From top outlet of it samples are collected for analysis. Pressure Regulator, Pressure Gauge and Safety Valve are fitted in the compressed air line.
Learning Objectives/Experiments:
To study the progress of a suitable Chemical Reaction CSTR.
To determine the Reaction Rate Constant.
Required for Operation:
Compressed Air Supply at 1 HP, 2 CFM.
Water Supply.
Drain.
Electricity Supply: 1 Phase, 220 V AC, 0.5 kW.
Instruments, Laboratory Glassware and Chemicals required for analysis as per the system adopted.
Control Panel:
Standard make on off switch, Mains Indicator etc.
