Composite Brige Plug For Oilifeld

Composite Brige Plug For Oilifeld

Price: 700.0 USD / Piece

Get Latest Price

Minimum Order Quantity :

1 Piece

In Stock

In Stock

Product Specifications

TypeFuel Pump
FOB PortQingdao
Payment TermsTelegraphic Transfer (T/T), Cash Advance (CA), Others
Supply Ability60 Per Month
Delivery Time1 Week
Sample PolicyContact us for information regarding our sample policy
Packaging DetailsPlywood case.
Main Export Market(s)Asia
Main Domestic MarketAll India
CertificationsAPI.ISO

Product Overview

Key Features


The Composite Bridge Plug is made from composite material and easy to drill out. It is mainly composed of mandrel, rubber, slips, cones, protection bowls, release/start pins, lower sub and so on. The composite bridge plug is mainly used for provisional plugging in oil and gas well, and fracturing construction

Working principle

The opposite power produced by setting tool (wire line or transmitting hydraulic pressure in oil tube) acts on the lower sub, shears the starting dowels and exerts compressive force on rubber through cone. Inside the tension range slips dehisce and inlay the in wall of the casing, rubber expand to the in wall of the casing and seal up it, finish setting. When the tension rises to the shear rating, the starting dowels be sheared and the setting tool separates from the bridge plug, finish releasing. After taking out the setting tool, the frac ball that be put into the well will work hermetically with the head face of the mandrel. The plug can be quickly drilled out under the necessity of the after steps

Drilling out

Recommend the use of special milling tools. Recommend rotation rate: 60~150rpm, bit weight: 5~15kN, viscosity of drilling plug fluid:15~30mPas and minimum cyclic velocity: 36.6m/min, to make sure the debris circulates out. After the preparation is done, start the screw drill and drill slowly into the bridge plug. Ensure continuous drilling speed by applying drilling pressure. The torque added to the drilling tool should not be greater than the recommended value. Excessive drilling pressure increases the friction resistance of the pipe string and results in large pieces of debris which must be salvaged separately.
Specification
Type
DTJ92
DTJ100
DTJ112
DTJ145
Suitable casing size
9.5-13.5lb/f99.56mm-103.88mm
13-18 lb/f108.62mm-114.14mm
17-23lb/ft 118.62mm-124.26mm
26-32lb/ft 154.78mm-159.42mm
Max OD
3.62"92mm
3.93(100mm)
4.4"112mm
5.68"144mm
Min ID
1.1"28mm
1.8(30mm)
1.5"38mm
1.14"45mm
Total length
26"660mm
26"660mm
26"660mm
39.4"1000mm
Working pressure
10000psi 70MPa
10000psi 70MPa
10000psi 70MPa
10000psi 70MPa
Working temperature
300150
300150
300150
300150
Seating load
120-130kN
160-180kN
160-180kN
160-180kN
