Black Cnc Lathe Electric Power Wet Polishing Disc Angle Grinder

We are Making and Exporting CNC Lathe Electric Power Wet Polishing Disc Angle Grinders in Beijing, China.

Quick Details
Condition: New Type: Universal CNC or Not: CNC Max. Grinding Diameter: 100mm Max. Grinding Length: 140mm Place of Origin: Beijing, China (Mainland) Brand Name: CHN-TOP Voltage: 380V 50Hz Power(W): 2.2KW Dimension(L*W*H): 1850*2100*1650(L*H*W) Weight: 2000KG Certification: CE ISO9001 After-sales Service Provided: Engineers available to service machinery overseas Color: Blue Brand: CTSTC Application: PCD/PCBN/Diamond tools/carbide Radius: 0-100mm Grinding Pressure: 0-450N adjustable
Product Description
Product Application
ZT-180 is a precision tools' grinding machine which in-corporate the necessary features required for the economical manufacturing and regrinding of a wide range of a wide range of PCD,PCBN,Carbide and HSS cutting tools.



SPECIFICATIONS FOR 25 TON CRAWLER EXCAVATOR

Grinding system
Grinding Radius
mm
0-100mm
Pressure
N
0-450N
Grinding speed
RPM
0-4500

CCD Measuring System
Magnification
Zone
7-45X
Min Radius
A mm
0.05R
Monitor
Brand
Samsung/ Lenovel

Pneumatic System
Vclinic Travel of Spindle
1mm
70mm
Oscillating Frequency of wheel
min
0-45/min
Vertical Travel of Spindle
mm
140

Design Features
1) Machine body and all casts are more than 18 months natural ageing

2) SCHNEEBERGER heavy duty and precision linear slide guide for its accuracy and life

3) Swing mechanism utilizing ball-screw by a servo motor,smoother ,more stable and durable. The whole pneumatic system use Japan SMC brand, to get rapid feed and infeed.

4) Linear grating and angle encoder of this model is FAGOR, make sure the precision indication.

5) CCD Camera with LCD monitor and precision scale for easy set up&inpsection in grinding

6) Optical system for adjustable from 7-45 magnification even 0.05 radius can be grinded and inspected.

Grinding samples




Detailed Images

Machine Parts
Name: Grinding Accessories

Brand: FUJITSU

Original: JAPAN

Spindle motor inverter produced by the FUJITSU company of Japan

Main Features
Name: Work table
Brand:CTSTC
Original: China
The work table size is 0-270 degree ,and it can be adjust.

Swivel table angle lock is by a adjustable handle lever.



Machine Parts
Name: CCD System
Brand:Nikon
Original: JAPAN
The CCD system is very famous camara with lenovo 17'' LCD monitor ,and can zoon 7-45 magnification. Even can grind R0.05

Our Service


Laser cutting service for PCD/PCBN/CVD
* 24 hours working and complete in 2 days

* Each piece is cleaned and visually inspected

* Precision cutting of PCD/PCBN/CVD

Brazing service
* Use vacuum brazing machine with efficient work

* Skilled experience with PCD/PCBN/CVD inserts and tips

Packing & Delivery

Packaging
Size
123 (L) * 116 (W) * 153 (D)
Weight
1.45 T



Packaging Details
The normal package is wooden box(Size: L*W*H). If there is any special requirements, we will make according to yours
Related Products



ZT-120R Rotary tools Grinder
98% Response Rate

ZT-120 PCD/PCBN Grinder
99.8% Response Rate

ZKHJ180 Vacuum brazing
99% Response Rate

FAQ
Q: Are you trading company or manufacturer ?
A: We are factory for PCD,CBN diamond tools equipments and services

Q: How long is your delivery time?
A: Generally it is 2-3 days for CNC diamonds tools machining,and 45-60days for machines

Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.

Q: What is your terms of payment ?
A: Payment=1000USD, 30% T/T in advance ,balance before shippment.
