Amorphous Ribbon Shearing Line - Special Alloy Construction, 140-220mm Cutting Size, 3000mm Cutting Width, Automatic Operation , Plc Control, 30 Tons/day Capacity

Amorphous Ribbon Shearing Line

l The product line is used for shearing and stacking of ribbon amorphous alloys.

l The product line is employed in high capacity PLC control,operationg system by serve motor,touch-screen and human-computer inter face and high precision transmission structure.

The components of product line

l The product line is made up of feeder system,main shearing instrument system,automatic stacking and arranging system,main control box and electric control system.



Feeding system

l It is equipped with three feeders,and can be used not only individually but also operated with main shearing instrument system jointly.

l Each feeder adopts stepless speed regulation control by transducer and automatic tracking control.



Technical specification

Cutting length

300-3500mm

Height of shearing core window

150-850mm

Cutting width

140-220mm

Width of shearing core window

30-450mm

Cutting thickness

The thickest have 15 layersi per layer was 0.025mmi

Thickness of shearing core window

25-130mm

Cutting speed

0-30times/min

Precision of shearing of length

A 0.5mm

Feed speed

5-90m/min

Position accuracy of stacking

A 0.5mm



Main shearing instrument system

l Feeding is driven by MSMA serve motor,and the upper feed roller is controlled by two cylinders with its pressure adjustable between 0 and 0.7Mpal.

l The head and body of the product line from detachable integrated structure,which is easy for main tenance.

l The cutting part adopt rolling guideway and high power serve motor and crank shift link mechanism to achieve precise shearing.



Main control box and electric control system

l The whole product line is operated by the main box.

l Giving material in ,cutting and stacking can be realized automatically when it is equipped with PLC intelligent control system.

l It is safe to set several scram buttons on the main control box.

l The pneumatic operation of each part is controlled by program adjustably.



Automatic stacking and arranging system.]

l Linear motion of laminated platform is achieved by serve motor via speed-change mechanism,gear and rack. The laminated platform is positioned by preset program to meet demand of different amorphous core.

l Thickness of lamination in vertical is controlled by cylinder hold-down mechanism with limit,which could be lowered to meet demand of cores.
