BUCHOLZ RELAY TEST SETUP (WITH COMPRESSOR & OIL)
Bucholz Relay Test Setup (with compressor & Oil)
For Studying Functional Performance of Buchholz Relay
For Graphical Plotting Characteristics Of The Relay Relay
Gas Volume Test: Alarm operated at 160cc
Trip operated at a steady Flow: 100 cm/ angle of mounting
Loss of Oil Test: Trip operated when oil level is dropped to bottom of the inlet port.
Surge Test: The Trip operated satisfaction on the application of a sudden
Insulation Resistance at Test Bed Temperature: Not less than 10 Mega ohm Control Unit: Consisting of MCB DP Input Protection
Indicators for Alarm, Trip & Mains.
Transformer Tank
Conservator Tank
Reservoir Tank
Valves & Foot Pump.
Complete Experimental Setup will be mounted on heavy duty M.S Angle Iron frame
Accessories: Instructional Manual, Patch Cords etc.
