Bias Cutter Machine By Luxmi Techno

Technical Specification:
Type : High Table Horizontal
Purpose : To automatically cut rubberized Nylon Fabric. from a let off station at adjustable cutting width and angle.
Maximum width of fabric that can be put : 1200 mm
Stock roll diameter : 1000 mm
Shell bar : 32 mm sq.
Liner width / Diameter : As per requirements
Length of shell : - do -
Cutting width : Max 800 mm min 150 mm
Cutting angle : 30A to 75A degree
Accuracy : Angle +/- 0.5 deg.
Accuracy : Width +/-1.5 mm
Conveyor table Length (from center of cutter carriage to the end of the table) : 4500 mm Approx.
Max Conveyor surface speed : 80 mts. per min.
Conveyor table width : 48"
Out put of the machine : 18 cuts per min. at 600 mm width of cut.
Thickness of the calendered fabric : 0.8mm to 2.5mm
Cutter speed : 5600 RPM
