Best Price Solar Pcu
Price:
Get Latest Price
In Stock
Product Specifications
| Payment Terms | Others, Telegraphic Transfer (T/T) |
| Delivery Time | 2 Week |
| Sample Policy | Contact us for information regarding our sample policy |
| Main Domestic Market | Karnataka |
Product Overview
Key Features
We are one the leading trader and supplier a myriad collection of Best Price Solar PCU in Bengaluru, Karnataka, India. Offered with us at rock bottom price range.
Product Details:-
Maximum asymmetric loadUp to Pcont.
Load detection (stand-by)2 to 25 W
Cos0.1-1
Transfer timeLess than 15ms
Protection indexIP20
Operating temperature range-20 to 55 deg C
Relative humidity in operation95% without condensation
Nominal battery voltage12-48 VDC
Maximum loadUp to short-circuit
ConditionNew
Output VoltagePure sine wave 230 Vac ( 2 %) / 120 Vac
Input Voltage9.5 - 17 Vdc
Size (W x H x D)133x322x466 mm
Output Frequency50 Hz
Ground Fault Monitoring / Grid MonitoringYes
DC Reverse Polarity ProtectionYes
Over Voltage / Current Limitation ProtectionYes
AC Short Circuit ProtectionYes
AC Over Voltage / Current Limitation ProtectionYes
Degree of ProtectionIP 65
Efficiency93%
CertificationCE, RoHS
TopologyTransformer Less
MNRE ApprovedYes
Warranty5 Year
Technical Details:-
Nominal battery voltage: 12VDC
Input voltage range: 9.5 - 17VDC
Continuous power @ 25 DegreeC : 1500VA
Power 30 min. @ 25 DegreeC : 1500VA
Power 5 sec. @ 25 DegreeC : 3.4kVA
Consumption OFF/Stand-by/ON: 1.2W/1.4W/8W
Maximum charging current :70 A
Input current max. (transfer relay) / Output current max. :50Aac/56Aac
Multifunction contacts : 2 independent contacts (potential free 3 points, 16Aac/5Adc)
Conformity: Directive EMC 2004/108/EC : EN 61000-6-1, EN 61000-6-3, EN 55014, EN 55022, EN 61000-3-2, 62040-2 Low voltage directive 2006/95/EC : EN 62040-1-1, EN 50091-2, EN 60950-1
Accessories:-
Remote control RCC-02 or RCC-03
Module XCOM-232i
Remote Control Module RCM-10 (3 m)
Cooling Module ECF-01
Battery temp. sensor BTS-01 (3 m)
Communication cable for 3ph
Product Details:-
Maximum asymmetric loadUp to Pcont.
Load detection (stand-by)2 to 25 W
Cos0.1-1
Transfer timeLess than 15ms
Protection indexIP20
Operating temperature range-20 to 55 deg C
Relative humidity in operation95% without condensation
Nominal battery voltage12-48 VDC
Maximum loadUp to short-circuit
ConditionNew
Output VoltagePure sine wave 230 Vac ( 2 %) / 120 Vac
Input Voltage9.5 - 17 Vdc
Size (W x H x D)133x322x466 mm
Output Frequency50 Hz
Ground Fault Monitoring / Grid MonitoringYes
DC Reverse Polarity ProtectionYes
Over Voltage / Current Limitation ProtectionYes
AC Short Circuit ProtectionYes
AC Over Voltage / Current Limitation ProtectionYes
Degree of ProtectionIP 65
Efficiency93%
CertificationCE, RoHS
TopologyTransformer Less
MNRE ApprovedYes
Warranty5 Year
Technical Details:-
Nominal battery voltage: 12VDC
Input voltage range: 9.5 - 17VDC
Continuous power @ 25 DegreeC : 1500VA
Power 30 min. @ 25 DegreeC : 1500VA
Power 5 sec. @ 25 DegreeC : 3.4kVA
Consumption OFF/Stand-by/ON: 1.2W/1.4W/8W
Maximum charging current :70 A
Input current max. (transfer relay) / Output current max. :50Aac/56Aac
Multifunction contacts : 2 independent contacts (potential free 3 points, 16Aac/5Adc)
Conformity: Directive EMC 2004/108/EC : EN 61000-6-1, EN 61000-6-3, EN 55014, EN 55022, EN 61000-3-2, 62040-2 Low voltage directive 2006/95/EC : EN 62040-1-1, EN 50091-2, EN 60950-1
Accessories:-
Remote control RCC-02 or RCC-03
Module XCOM-232i
Remote Control Module RCM-10 (3 m)
Cooling Module ECF-01
Battery temp. sensor BTS-01 (3 m)
Communication cable for 3ph
