Automatic Terminal Crimping Equipment (Hpc-3020)

We are introducing wide range of Fully Automatic Terminal Crimping Machine. These are applicable for automobile harness processing. These are available as per following specification:

Both ends crimping .
Crimp Force Monitoring feature .
Applicable wire ranges : 0.13-5.0 mmA i AWG28-AWG10).
Water-proof putting device and ink injecting device can be optional .
Use special overlay belts to feed the wires.
Touch screen computer, operating easily.
Waste automatic processed.
Model HPC-1010 T
Cutting Length30mm - 65000mm
Stripping LengthFront end: 0.1mm-15mm, Rear end: 0.1mm-15mm
Cutting Accuracya A (0.2%+1.0mm)(Depend on equipment adjustment and wire materials)
Wire Range0.13 - 5.0 mmA i AWG28-AWG10)
Crimping force2 ton
Power 3 phase a 380 V / 50 a 60Hz
Productivity6m/s 40m/sA
Noise level < 75 dB (without crimp modules)
Air Source 0.5 Mpa
Air Consumption6.5 m3/h
Dimensions1300mm(W) A 3500mm(L)A 1250mm(H)
Weight 1200Kg
