Automatic Hot-stamping Machine (Sf-ahr60)

Our offered Automatic Hot-Stamping Machine (SF-AHR60) is precisely designed and manufactured, using internationally famous brands electrical components in the operational performance and stamping quality and has shown the appearance in the perfection of this machine. It is equipped with automatic high-capacity feeders, which can not only save human resources, but also show the high-speed operation of this machine.

Automatic Hot-Stamping Machine (SF-AHR60) is also equipped with no parts no stamping, no material with hopper alarm system, low air-pressure alarm, lack of hot-stamping foil alarm in order to ensure the continuity and stability of machine operation. In place with an automatic feed detection, you can reduce the course of transmission of the work-piece"s surface such as wear or scratches.

Besides, SF-AHR60 is equipped with mechanical transmission and PLC control, with a speed of 3600pcs/hour; at the same time, universal fixtures have been adopted, just replacing the little parts and an appropriate adjustment can be achieved by changing product models fastly(only 30 minutes to change the Convention).

Specifications:
1. Type: SF-AHR60
2. Printing product size(Dia.X Length):(I 18~50mm)x(25~70mm)
3. Maximum Printing Area:70mmx150mm
4. Maximum Running Speed:60pcs/min
5. Compressed Air pressure:5-7bar
6. Power Consumption:220V/2P 50//60Hza 4.2Kw
7. Machine Dimension(LXWXH):1500x850x1900mma
8. Weight:864KG
