Automatic High Speed Four Head Ropp / Screw Cap Sealing Machine

<p><u><strong>Automatic High Speed Four Head ROPP / Screw Cap Sealing Machine</strong></u></p><p>&nbsp;</p><table width="700" cellspacing="0" cellpadding="0" border="0" align="center"><tbody><tr><td valign="top" align="left" class="maintxt"><strong>LAXMI</strong> Automatic High Speed Four Head ROPP / Screw Cap Sealing Machine Model <strong>LRCS –120,&nbsp; &nbsp;</strong>It is<strong> </strong>supporting to our range of Bottle Filling from Semi-Automatic to Automatic line<strong> </strong>Previously filled bottles with Dry Syrup Powder or Liquid Syrup are continuously fed from filling machine to the flat conveyor belt of sealing machine and move further through Infeed worm for correct spacing between two bottles and transferred to the Infeed star wheel. ROPP / Screw caps kept in orientation unit automatically orient caps in right direction before entering into delivery chute. And Bottle is entering below the sealing head, consist of total four rollers. Two rollers properly Skirts, Spins and Seals the cap and simultaneously another two roller performs perfect threading according to bottle neck diameter. After sealing operation, sealing head moves upward with help of cam and bottle move with exit star wheel and Move further on conveyor belt for next operation.<br /> <br /> The machine consist of turntable, S.S. slat conveyor belt, Feedworm, Bowl &amp; Chute, Infeed &amp; Exit Star plate &amp; Back Guide, easy –reach compact panel and with no container - no cap, No sealing System etc. The Sealing unit and Cap orientation unit are mounted on two pillars which in turn are supported by top plate with individual height adjusting system and Damage cap quantity can be reduced by help of automation system.&nbsp; All its exposed parts are made of S.S. – 304. Its height can be adjusted to match other machines for efficient synchronization.</td> </tr> <tr> <td valign="top" height="10" align="left"><br /></td> </tr> <tr> <td height="30" background="images/bg_image.png" align="left" class="style2"><span class="style1">Silent Feature</span> :</td> </tr> <tr> <td valign="top" height="10" align="left"><br /></td> </tr> <tr> <td valign="top" align="left"><table width="100%" cellspacing="0" cellpadding="0" border="0" align="center"> <tbody> <tr> <td width="10" valign="baseline" height="20" align="left"><img width="10" height="9" border="0" src="http://laxmipharmaequipments.com/images/bullet1.jpg" /></td> <td height="20" align="left" class="maintxt">All Liquid Contact Parts are of S.S. 316, the Body Structure is built up of S.S. 304 Pipe.</td> </tr> <tr> <td valign="baseline" height="20" align="left"><img width="10" height="9" border="0" src="http://laxmipharmaequipments.com/images/bullet1.jpg" /></td> <td height="20" align="left" class="maintxt">Single motor synchronizes conveyor, star wheels and platform turret and speed can be varied by the % speed pot on operating panel.</td> </tr> <tr> <td valign="baseline" height="20" align="left"><img width="10" height="9" border="0" src="http://laxmipharmaequipments.com/images/bullet1.jpg" /></td> <td height="20" align="left" class="maintxt">A Special clutch device is incorporated on the in feed worm and Star wheel system for stoppage of machine in the event, vial is over turned or over diameter.</td> </tr> <tr> <td valign="baseline" height="20" align="left"><img width="10" height="9" border="0" src="http://laxmipharmaequipments.com/images/bullet1.jpg" /></td> <td height="20" align="left" class="maintxt">Spring loaded free spinning sealing rollers eliminates any damage to aluminum caps and also allows greater flexibility of variation in the container neck diameter.</td> </tr> <tr> <td valign="baseline" height="20" align="left"><img width="10" height="9" border="0" src="http://laxmipharmaequipments.com/images/bullet1.jpg" /></td> <td height="20" align="left" class="maintxt">Sealing Pressure can be varied to suit different gauges and sizes of aluminum caps.</td> </tr> <tr> <td valign="baseline" height="20" align="left"><img width="10" height="9" border="0" src="http://laxmipharmaequipments.com/images/bullet1.jpg" /></td> <td height="20" align="left" class="maintxt">Digital Counter for counting number of sealed vials.</td> </tr> <tr> <td valign="baseline" height="20" align="left"><img width="10" height="9" border="0" src="http://laxmipharmaequipments.com/images/bullet1.jpg" /></td> <td height="20" align="left" class="maintxt">No Bottle - No Cap, Machine Stop System</td> </tr> <tr> <td valign="baseline" height="20" align="left"><img width="10" height="9" border="0" src="http://laxmipharmaequipments.com/images/bullet1.jpg" /></td> <td height="20" align="left" class="maintxt">Damage cap quantity can be reduced by help of automation system</td> </tr> <tr> <td valign="baseline" height="20" align="left"><img width="10" height="9" border="0" src="http://laxmipharmaequipments.com/images/bullet1.jpg" /></td> <td height="20" align="left" class="maintxt">Star wheel is equipped with safety clutch for automatic stoppage of machine in case of jamming or over loading through micro switch.</td> </tr> </tbody> </table></td> </tr> <tr> <td valign="top" height="10" align="left"><br /></td> </tr> <tr> <td valign="top" align="left"><table width="100%" cellspacing="1" cellpadding="5" border="0" bgcolor="#c7c7c7" align="center"> <tbody> <tr> <td valign="middle" height="30" bgcolor="#404040" align="center" colspan="2" class="style2"><strong>TECHNICAL SPECIFICATION</strong></td> </tr> <tr> <td valign="middle" height="25" bgcolor="#ebebeb" align="left" class="client_list_txt"><strong>Model No</strong></td> <td valign="middle" height="25" bgcolor="#ffffff" align="left" class="client_list_txt">LRCS 120</td> </tr> <tr> <td valign="middle" height="25" bgcolor="#ebebeb" align="left" class="client_list_txt"><strong>Filling Heads</strong></td> <td valign="middle" height="25" bgcolor="#ffffff" align="left" class="client_list_txt"><p>4 Heads</p></td> </tr> <tr> <td valign="middle" height="25" bgcolor="#ebebeb" align="left" class="client_list_txt"><strong>Output/ Min</strong></td> <td valign="middle" height="25" bgcolor="#ffffff" align="left" class="client_list_txt">120 VBM </td> </tr> <tr> <td valign="middle" height="25" bgcolor="#ebebeb" align="left" class="client_list_txt"><strong>Power Characteristics</strong></td> <td valign="middle" height="25" bgcolor="#ffffff" align="left" class="client_list_txt">440v 3 Phase 50Hz 4 Wire System</td> </tr> <tr> <td valign="middle" height="25" bgcolor="#ebebeb" align="left" class="client_list_txt"><strong>Cap Size</strong></td> <td valign="middle" height="25" bgcolor="#ffffff" align="left" class="client_list_txt">22mm, 25mm, 28mm</td> </tr> <tr> <td valign="middle" height="25" bgcolor="#ebebeb" align="left" class="client_list_txt"><strong>Filling Accuracy</strong></td> <td valign="middle" height="25" bgcolor="#ffffff" align="left" class="client_list_txt"><p>±1 %</p></td> </tr> <tr> <td valign="middle" height="25" bgcolor="#ebebeb" align="left" class="client_list_txt"><strong>Net Weight </strong></td> <td valign="middle" height="25" bgcolor="#ffffff" align="left" class="client_list_txt">950 kgs</td> </tr> <tr> <td valign="middle" height="25" bgcolor="#ebebeb" align="left" class="client_list_txt"><strong>Machine Length </strong></td> <td valign="middle" height="25" bgcolor="#ffffff" align="left" class="client_list_txt">1600mm</td> </tr> <tr> <td valign="middle" height="25" bgcolor="#ebebeb" align="left" class="client_list_txt"><strong>Machine width</strong></td> <td valign="middle" height="25" bgcolor="#ffffff" align="left" class="client_list_txt">790mm</td> </tr> <tr> <td valign="middle" height="25" bgcolor="#ebebeb" align="left" class="client_list_txt"><strong>Machine height </strong></td> <td valign="middle" height="25" bgcolor="#ffffff" align="left" class="client_list_txt">1800mm</td> </tr> </tbody> </table></td> </tr> <tr> <td valign="top" height="10" align="left"><br /></td> </tr> <tr> <td height="30" background="images/bg_image.png" align="left" class="style2"><span class="style3"><strong>Application</strong> :</span></td> </tr> <tr> <td valign="top" height="10" align="left"><br /></td> </tr> <tr> <td valign="top" align="left"><table width="100%" cellspacing="0" cellpadding="0" border="0" align="center"> <tbody> <tr> <td width="10" valign="baseline" height="20" align="left"><img width="10" height="9" border="0" src="http://laxmipharmaequipments.com/images/bullet1.jpg" /></td> <td height="20" align="left" class="maintxt">Pharmaceuticals</td> </tr> <tr> <td valign="baseline" height="20" align="left"><img width="10" height="9" border="0" src="http://laxmipharmaequipments.com/images/bullet1.jpg" /></td> <td height="20" align="left" class="maintxt">food &amp; beverages</td> </tr> <tr> <td valign="baseline" height="20" align="left"><img width="10" height="9" border="0" src="http://laxmipharmaequipments.com/images/bullet1.jpg" /></td> <td height="20" align="left" class="maintxt">Pesticide</td> </tr> <tr> <td valign="baseline" height="20" align="left"><img width="10" height="9" border="0" src="http://laxmipharmaequipments.com/images/bullet1.jpg" /></td> <td height="20" align="left" class="maintxt">chemicals</td> </tr> <tr> <td valign="baseline" height="20" align="left"><img width="10" height="9" border="0" src="http://laxmipharmaequipments.com/images/bullet1.jpg" /></td> <td height="20" align="left" class="maintxt">cosmetic</td> </tr> <tr> <td valign="baseline" height="20" align="left"><img width="10" height="9" border="0" src="http://laxmipharmaequipments.com/images/bullet1.jpg" /></td> <td height="20" align="left" class="maintxt">And in other allied company and industries.</td></tr></tbody></table></td></tr></tbody></table>
