Automatic Folder Gluer Stitcher and Counter Ejector

Automatic Folder Gluer Stitcher And Counter Ejector Capacity: 100 T/day Ton/day


Price: 2500000.00 INR / Set

(2500000 INR + 0% GST)whatsappWhatsAppGet Latest Price
1 Pack Contains: 1Minimum Pack Size: 5
Get Latest Price

In Stock


Delivery Time

: 60 Days

Supply Ability

: 10 Per Month


BUY NOW

Delivery & Payment Options

payment-logo
  • Cash Against Delivery (CAD)

  • Letter of Credit (L/C)

  • Telegraphic Transfer (T/T)

  • Cash in Advance (CID)

Product Overview

Key Features

1a Max. gluing speed will be 11000pcs/hour, and stitching speed will be 6000pcs/hour, which improves productivity greatly.
2a The whole machine adopts PLC, touch screen combined with Servo Motor for controlling can also adjust motorized by Button. Baffle, Stitching distance, Stitching quantities are automatic adjusted by input data; Paper lifting, Folding, Stitching head belts, Squaring, Creasing, Distance are motorized adjusted.
3a Paperboard feeding, gluing, folding, stitching, adjusting, counting and stacking can be done automatically.
4a Feeding unit designed with vacuum suction, and adopted leather belt for paperboard delivery.
5a It equipped creasing and re-creasing function so that even more accurate when folding.
6a Adopted timing belts for main driver, which conveys paperboard precisely.
7a The stitching unit equipped with 5 groups servo motor, synchronous matching with flapping, stitching, and conveying.
Equipped with two servo motor for flapping, to ensure carton is well squared.
Independent servo control to make sure accurate stitching distance, stitching quantities can be adjusted.
Independent servo control of Upper & Lower synchronous belts, perfectly matching with stitching heard, to make sure accurate transfer.
Conveyor belts can be adjusted to correct Scissors shape tail, folding position can be micro-adjusted to control big & small gap.
8a Lifting splicer is equipped between Stitching & Counter Ejector Unit, which makes more easy maintain of Stitching Unit.
9a Auto counting, squaring, stacking, and conveying in Counter Ejector Unit.
10a Can easy match with automatic strapping machine.

Automatic Folder Gluer Stitcher and Counter Ejector Specification

Color

Any

General Use

Automatic Folder Gluer (Stitcher) Machine, Find details about ... nail head part, count pushing part, automatic binding part (optional) and electrical ... (9) The main motor of counting ejector the speed is frequency adjusted, ... (11) The flapping baffles are used for correcting the boxes, the deviation is very small.

Material

Paper

Type

Cardboard Gluing Machine

Capacity

100 T/DAY Ton/day

Weight (kg)

10000 KG Kilograms (kg)

Computerized

No

Automatic Grade

Fully Automatic

PLC Control

Yes

Drive Type

Electric

Voltage

380 V Volt (v)

Dimension (L*W*H)

145000 x4000 x2300 mm Millimeter (mm)

Conveyor Speed

100 M/M m/m

Sealing Speed

600 STITCHES/ MIN

Max.Feeding Size

1600A--3600 MM

Min.Feeding Size

900A--2000 MM

Product Unit

5 Set/Sets

Currency

INR

Price

2500000.00 INR (Approx.)

Unit Type

Set/Sets

Price Type

fixed

Brand Name

Nagpal Natraja

Packsize

1

Mop

5

Stock Quantity

10

Moq

5

Returnable

No

GSTIN

0%

Main Domestic Market

All India

Certifications

ISO

FOB Port

DELHI

Packaging Details

Loose
