Ac Motors (Low Voltage Motors Spectrum Series)

We have gained a reputed position in our domain by manufacturing trading and supplying a varied variety of AC Motors (Low Voltage Motors Spectrum Series) in Ahmedabad Gujarat India.

FEATURES:-
Ambient Temperature -10 to +50 C
Altitude Not exceeding 1000mtrs above mean sea level.
Atmosphere Non corrosive & non hazardous
Relative Humidity Up to 100%
Voltage 415V 10% 3 pH
Frequency 50Hz 5%
Combined Variation 10%
Duty S1 (continuous)
Service factor 1.0

FEATURES:-
Starting Star Delta/DOL (with shorting links but with 2 entries)
Permissible starts/hr. Cold successive - 4 hot successive - 3 equally spread - 6
Loading at reduced volts 75% Rated volts for 5 minutes
Insulation / temp.rise Class `F' / 70 deg. C
Direction of rotation Bi-directional
No. Of leads 6
Connection. Delta
Degree of protection IP 55
Method of cooling IC 411
T.box position RHS looking from driving end
Bearing life
(90% survival basis) 40000 working hrs. For direct drive
20000 working hrs. For belt drive
Vibration Normal class as per IS 12075
Noise As per IS 12065
Construction Foot 'B' flange Foot cum 'B' flange
Frame sizes SC 180 to 355 (For 'B' flange mounting ratings covered in SC180M to be offered in VSC180L & ratings covered in SC225S to be offered in VSC225M)
Shaft extension Single cylindrical extension as per IS: 1231
Body material Cast iron
T.box material Cast iron up to 225 frame mild steel for 250 to 355 frame
